ACS ACR123U ACS RFID Smart card ACR123U

The ACR123U is the USB version of the ACR123S, a cost-effective, flexible and intelligent contactless reader. It can be integrated to existing (Point-of-Sale) terminals or cash registers, to offer the convenience of a cashless payment system. The ACR123U speeds up movement in checkout counters, by enabling customers to complete payments by simply tapping their cards.

The ACR123U is equipped with a large graphical LCD that allows merchants to display messages, as well as a large tapping area with backlight, which guides customers in carrying out their payment transactions. Developed based on 13.56 MHz contactless (RFID) technology, it supports any contactless card following the ISO 14443-4 standard. It is also equipped with a large graphical LCD, as well as a large user-controllable tapping area with backlight.

Design



Backlight



Yes


Built-in display



Yes


Cable length



1.5 m


Display type



LCD


Product colour



Black


Display



Backlight



Yes


Built-in display



Yes


Display type



LCD


Features



Cable length



1.5 m


Compatible products



Support for ISO 14443 Part 4 Type A and B cards and MIFARE series


Compliance industry standards



ISO 14443 ISO 7816 (SAM Slot) USB Full Speed PC/SC CCID VCCI (Japan) KC (Korea) Microsoft� WHQL CE FCC RoHS 2 REACH


Frequency



13.56 MHz


Maximum read range



5 cm


Product colour



Black


Package dimensions



Gross Weight (Package, kg)



0.1 kg


Ports & interfaces



Compliance industry standards



ISO 14443 ISO 7816 (SAM Slot) USB Full Speed PC/SC CCID VCCI (Japan) KC (Korea) Microsoft� WHQL CE FCC RoHS 2 REACH


Interface



USB 2.0


Supported protocols



ISO 14443-4 Compliant Card, T=CL MIFARE� Classic Card, T=CL


Power



Power source



USB


USB powered



Yes


Product dimensions



Net Weight (Product, kg)



0.09000000000000001 kg


Product Depth



15.9 cm


Product Height



2.1 cm


Product Width



10 cm


System requirements



Linux operating systems supported



Yes


Windows operating systems supported



Windows CE


Vendor information



Brand Name


ACS


Warranty



1 Year(s)
