ACTi A815 A815 A815

Audio



Audio system



2-way


Sample rate



8 kHz


Voice codecs



G.711


Camera



Adjustment shutter speed



Auto/Manual


Angle of rotation



180 �


Camera pan control



Yes


Camera shutter speed



1/5-1/64000 Second


Camera shutter type



Electronic


Camera tilt control



Yes


Lens viewing angle, horizontal



90.6 �


Lens viewing angle, vertical



67.6 �


Minimum illumination



0.005 lx


Pan range



-135 - 135 �


Tilt angle range



0 - 90 �


Design



Form factor



Dome


IK code



IK10


International Protection (IP) code



IP66


Mounting type



Ceiling/wall


Product colour



White


Image sensor



Number of effective pixels (H x V)



2065 x 1553 Pixels


Number of sensors



1


Optical sensor size



1/2.8 "


Progressive scan



Yes


Sensor type



CMOS


Lens system



Focal length range



2.8-12 mm


Maximum aperture number



2.8


Minimum aperture number



1.4


Number of lenses



1


Optical zoom



4.3 x


Zoom capability



Yes


Management features



Behavior analysis



P�visning af indtr�ngen, Registrering af linjeoversk�ring, Registrering af objektfjernelse, Registrering af uoverv�get bagage


Firmware upgradeable



Yes


Reset button



Yes


Network



Bluetooth



No


Ethernet LAN



Yes


Networking standards



IEEE 802.1x, IEEE 802.3af


Quality of Service (QoS) support



Yes


Supported network protocols



IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP


Wi-Fi



No


Night vision



Infra-red wavelength



850 nm


LED type



IR


Night vision



Yes


Night vision distance



30 m


Operational conditions



Operating relative humidity (H-H)



20 - 80 %


Operating temperature (T-T)



-40 - 50 �C


Package dimensions



Gross Weight (Package, kg)



1.245 kg


Packaging content



Number of cameras



1


Performance



Connectivity technology



Wired


Day/night mode



Yes


Placement supported



Outdoor


Type



IP security camera


Wide Dynamic Range (WDR)



Yes


Power



DC output voltage



12


Power consumption (Power over Ethernet (PoE))



10 Watt


Power source type



DC, PoE


Product dimensions



Net Weight (Product, kg)



1.245 kg


Product Depth



5.5 cm


Product Height



13.9 cm


Product Width



12.9 cm


Security



HTTPS encryption



Yes


Intelligent Video Surveillance (IVS) system features



People counting


IP address filtering



Yes


Password protection



Yes


Video motion detection



Yes


Storage



Built-in HDD



No


Card reader integrated



Yes


Compatible memory cards



MicroSD (TransFlash), MicroSDHC, MicroSDXC


Maximum memory card size



256 GB


Vendor information



Brand Name


ACTi


Homepage



A815 | ACTi Corporation


Warranty



3 Year(s)


Video



Frame rate



30 fps


Gain control type



Auto


Image quality adjustment



Brightness, Contrast, Saturation, Sharpness


Image stabilizer



Yes


Maximum resolution



2048 x 1536 Pixels


Noise reduction



Yes


Noise reduction technology



2D noise reduction, 3D noise reduction


Privacy masking



Yes


Total megapixels



3 MP


Video compression formats



H.264, H.265, M-JPEG


Video streaming



Yes


Weight & dimensions



Diameter



13.938 cm
