ACTi E54 E54 5M Indoor Adaptive IR WDR E54

• 5 Megapixel with 1080p
• Day & Night with IR LED
• Fixed Lens with f3.6mm/ F1.8
• Basic WDR (69 dB)
• 30 fps at 1920 x 1080

Camera



Camera shutter speed



0.2 - 0.0001 Second Second Second


Camera shutter type



Electronic, Mechanical


Lens viewing angle, horizontal



72 °


Pan range



0 - 330 °


Tilt angle range



20 - 90 °


Viewing angle, horizontal



72 °


White balance



Auto, Manual


Design



Form factor



Dome


Product colour



Black, White


Image sensor



Optical sensor size



1/3.2 "


Sensor type



CMOS


Lens system



Fixed focal length



3.6 mm


Network



Cabling technology



10/100Base-T(X)


Ethernet LAN



Yes


Supported network protocols



TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP


Wi-Fi



No


Night vision



Infra-red wavelength



850 nm


LED type



IR


Night vision



Yes


Night vision distance



15 m


Number of illumination LEDs



10


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



-10 - 50 °C


Package dimensions



Depth (package,cm)



16.9 cm


Gross Weight (Package, kg)



1 kg


Height (package,cm)



16.9 cm


Width (package,cm)



16.9 cm


Packaging content



Manual



Yes


Performance



Connectivity technology



Wired


Day/night mode



Yes


Placement supported



Indoor


Wide Dynamic Range (WDR)



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Interface



RJ-45


Power



Power consumption (typical)



6.49 Watt


Power over Ethernet (PoE)



Yes


Power source type



PoE


Product dimensions



Net Weight (Product, kg)



0.29 kg


Product Height



9.9 cm


Security



HTTPS encryption



Yes


IP address filtering



Yes


Storage



Built-in HDD



No


Vendor information



Brand Name


ACTi


Warranty



3 Year(s)


Video



Frame rate



30 fps


Maximum resolution



2592 x 1944 Pixels


Supported graphics resolutions



320 x 240, 2592 x 1944, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 640 x 480 (VGA)


Total megapixels



5 MP


Video formats supported



H.264, M-JPEG


Weight & dimensions



Diameter



12.8 cm
