Allied Telesis AT-TQ6702 GEN2-00 At-Tq6702 Gen2 2401.9 Mbit/S AT-TQ6702 GEN2-00

The Allied Telesis Enterprise-class TQ6702 GEN2 hybrid wireless AP features Wi-Fi 6 technology with 8 spatial streams (8x8) to deliver a raw capacity of 4.8 Gigabits. Multi-Gigabit uplink ports ensure maximum wireless network performance and eliminate bottlenecks.

Antenna



Antenna direction type



Omni-directional


Antenna gain level (max)



5.93 dBi


Antenna type



Internal


Design



Cable lock slot



Yes


Cable lock slot type



Kensington


LED indicators



Y, Yes


Placement



Wall


Product colour



White


Features



2.4 GHz



Yes


5 GHz



Yes


6 GHz



No


Airtime Fairness (ATF)



Yes


Band steering



Yes


Cabling technology



10/100/1000Base-T(X)


Ethernet LAN data rates



10, 100, 1000, 2500, 5000


Fast roaming



Yes


Flow control support



Yes


Frequency band



2.4 GHz


Maximum data transfer rate



2401.9 Mbit/s


MIMO



Yes


MIMO type



Multi User MIMO


Networking standards



IEEE 802.11ax, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x


Quality of Service (QoS) support



Yes


VLAN support



Yes


Wi-Fi Multimedia (WMM)/(WME)



Yes


Wireless isolation



Yes


Management features



Firmware upgradeable



Yes


Syslog



Yes


Web-based management



Yes


Operational conditions



Operating altitude



0 - 3048 m


Operating relative humidity (H-H)



5 - 90 %


Operating temperature (T-T)



0 - 50 °C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-25 - 70 °C


Package dimensions



Gross Weight (Package, kg)



1.16 kg


Packaging content



Number of products included



1 pc(s)


Ports & interfaces



Ethernet LAN (RJ-45) ports



2


Power



AC input voltage



100 - 240 V


Power consumption (max)



24 Watt


Power consumption (typical)



19 Watt


Power over Ethernet (PoE)



Yes


Product dimensions



Net Weight (Product, kg)



0.89 kg


Product Depth



0.31 cm


Product Height



0.08 cm


Product Width



0.28 cm


Protocols



DHCP client



Yes


Management protocols



SNMPv1, v2c, v3


Security



Auto Wireless Distribution System (WDS)



Yes


MAC address filtering



Yes


Remote Authentication Dial-In User Service (RADIUS)



Yes


Security algorithms



802.1x RADIUS, SSID, WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise


Service Set Identifier (SSID) features



Hidden SSID


Sustainability



Sustainability compliance



Yes


Vendor information



Brand Name


Allied Telesis


Warranty



1 Year(s)
