Alogic DUPRDX3-WW Dx3 Triple 4K Display DUPRDX3-WW

Designed to expand the capabilities of any laptop. Engineered for compatibility across all Windows, MacOS and ChromeOS laptops, the DX3 dock provides access to all of the ports required in a home office, education, or corporate environment.

IMMERSIVE TRIPLE 4K

Sometimes you need more screen real estate. The DX3 can connect up to three external displays at 4K resolutions through its triple DisplayPort outputs*

Whether you need to view big spreadsheets on multiple screens, compare designs, enter data or more, the DX3 is the perfect way to see more work on your screen, and do more work on your screen.

*The available resolution of the third video output depends on the capabilities of the computer used with the docking station. Refer to the Display Resolution Table below for details on the output capabilities of computers based on their specifications.

SMALL DESK FOOTPRINT. BIG PERFORMANCE

The DX3�s compact design occupies minimal desk space to deliver premium performance. It's the ideal dock for a distraction-free desk set up focused on productivity.

USB-C & USB-A LAPTOP COMPATIBLE

IT decision-makers and organisations have more options with the DX3. It supports USB-C and USB-A laptop deployment.

LED Power Light

Lock Slot

VESA Mount

DUAL/TRIPLE DISPLAY ON M1 MAC

M1 Mac users can work on up to three screens when they plug into the DX3.

MADE WITH DISPLAYLINK

The DX3�s DisplayLink technology boosts your connectivity, power and productivity at work.

Logistics data



Harmonized System (HS) code



84733020


Network



Ethernet LAN



Yes


Ethernet LAN (RJ-45) ports



1


Ethernet LAN data rates



1000


Package dimensions



Gross Weight (Package, kg)



2.47 kg


Packaging content



AC adapter included



Yes


Cables included



AC, USB Type-C


Interface adapters included



USB Type-C male - USB Type-A female


Manual



Yes


Packaging data



Quantity per pack



1 pc(s)


Performance



Cable lock slot



Yes


Card reader integrated



Yes


Certification



FCC


Charging function



Yes


Compatible memory cards



MicroSD (TransFlash), SD


Display modes



Extended, Mirror


Housing material



Acrylonitrile butadiene styrene (ABS)


LED indicators



Y, Yes


Maximum digital resolution



5120 x 2880 Pixels


Number of displays supported



3


On/off switch



Yes


Plug and Play



Yes


Product colour



Black, Grey


Ports & interfaces



Combo headphone/mic port



Yes


Connectivity technology



Wired


DC-in jack



Yes


DisplayPort version



1.4


DisplayPorts quantity



3


Headphone connectivity



3.5 mm


Headphone outputs



1


Host interface



USB 3.2 Gen 1 (3.1 Gen 1) Type-C


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



3


USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity



1


USB Power Delivery



Yes


USB Power Delivery up to



100 Watt


USB Sleep-and-Charge



Yes


Power



Compatible power plug types



AU, EU, UK, US


Power source type



AC


Power supply



135 Watt


Product dimensions



Net Weight (Product, kg)



1.9 kg


Product Depth



9 cm


Product Height



0.65 cm


Product Width



19 cm


Software



Mac operating systems supported



Y, Yes


Windows operating systems supported



Yes


Sustainability



Sustainability certificates



RoHS, CE


Vendor information



Brand Name


Alogic


Warranty



1 Year(s)
