APC AP6020A Rack PDU Basic 0U/1U 100-240V/ AP6020A

AP6020AFeatures

- Rack PDU, Basic, 0U/1U, 100-240V/20A, 220-240V/16A, (13) C13
- Reliable rack power distribution
- Includes : Installation guide , Safety guide

Marketing Features

Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.

Agility

Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.

Total Cost of Ownership

Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.

Design



Mounting



Horizontal/Vertical


PDU types



Basic


Product colour



Black


Rack capacity



0U/1U


Type



Single-phase


Features



Certification



cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH


RoHS compliance



Yes


Operational conditions



Operating altitude



0 - 3048 m


Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 50 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-15 - 60 �C


Package dimensions



Depth (package,cm)



43.8 cm


Gross Weight (Package, kg)



1.86 kg


Height (package,cm)



9.2 cm


Width (package,cm)



22.2 cm


Packaging data



Package dimensions (WxDxH)



210 x 76 x 436 mm


Ports & interfaces



AC outlet types



C13 coupler


AC outlets quantity



13 AC outlet(s)


Output connections



IEC 320 C13


Power plug



C20 coupler


Power



AC input frequency



50 - 60 Hz


Load capacity



3680 VA


Maximum current



20 A


Maximum input current per phase



16 A


Maximum power



3680 Watt


Maximum total current draw per phase



16 A


Nominal input voltage



100-240 V


Product dimensions



Net Weight (Product, kg)



1.795 kg


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


APC


Warranty



1 Year(s)


Weight & dimensions



Dimensions (WxDxH)



44 x 93 x 388 mm
