APC APDU10350SM Power Distribution Unit Pdu APDU10350SM

APC NetShelter Rack PDU Advanced, Switched Metered Outlet, 17.3kW, 3PH, 415V, 30A, 530P6, 48 Outlet
APC NetShelter Rack PDU Advanced provide reliable power distribution to IT Equipment within server and/or networking racks. Switched outlets to turn outlets on or off remotely. Outlet and PDU level power metering for power visibility and notification of potential overload. 4-in-1 combination outlets which can be used as either C13, C19, C15, or C21 outlets provide unparreled deployment flexibility. Maximum outlet density with 48 outlets in a 2.2" wide form factor. Outlets on the PDUs are color coded and/or labeled by breaker and input phase on 3 phase models to simplify deployment. Provides an alternating phase design whereby each of the 3 phases are organized into small outlet groups which alternate from top to bottom of the PDU to facilitate better power cord management and promote better load balancing. Power Sharing allows PDUs cascaded together via 2 ethernet ports enable an Network Management Card to continue functioning in the event of an AC power loss. No interruption in Network communication, sensors operation, and alarm traps. Live Swap Network Management Card (NMC) which can be replaced without powering down the PDU or connected devices to minimize downtime in the unlikely event of an NMC power event. Rated and approved to operate up to 60C (140F) at full load ensures reliability and availability even in today's high density deployments. Gigabit ethernet to enhance and standardize network connectivity across all assets in the data center. A second ethernet port (10/100) is available to allow cascading to other PDUs, connect to a 2nd private network, or provide network redundancy. 1% metering accuracy for the peace of mind to use NetShelter Rack PDU Advanced to bill based on power usage. In addition, the higher level of accuracy ensures the most precise measures for capacity planning and threshold alarm monitoring. Two environmental sensor ports allow for optional sensors (sold separately) to be connected. For data center deployments across multiple regions, these PDUs are both UL and CE rated providing one PDU that can be used globally to simplify and standardize deployment.

Design



Display



LCD


Mounting



Vertical


On/off switch



No


PDU types



Metered, Metered-by-outlet, Switched


Product colour



Black


Rack capacity



0U


Type



Three-phase


Features



Certification



CE, CSA C22.2 No 62368-1, EN 62368-1, FCC part 15 subpart B, UKCA, UL 62368-1


Operational conditions



Operating altitude



0 - 15240 m


Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



-5 - 60 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-25 - 65 �C


Package dimensions



Depth (package,cm)



13.2 cm


Gross Weight (Package, kg)



1.29 kg


Height (package,cm)



198 cm


Width (package,cm)



26.2 cm


Ports & interfaces



AC outlet types



C13 coupler, C15 coupler, C19 coupler, C21 coupler


AC outlets quantity



48 AC outlet(s)


Power plug



IEC 60309


Power



AC input frequency



50 - 60 Hz


Load capacity



22100 VA


Maximum current



32 A


Nominal input voltage



400 V


Nominal output voltage



230 V


Output voltage



230 V


Product dimensions



Net Weight (Product, kg)



0.99 kg


Product Depth



7.5 cm


Product Height



178 cm


Product Width



5.6 cm


Vendor information



Brand Name


APC


Warranty



1 Year(s)
