APC GVSUPS15KB4HS Uninterruptible Power Supply GVSUPS15KB4HS

GVSUPS15KB4HS Features

- Galaxy VS UPS 15kW 400V, 1 internal 9Ah smart modular battery string, expandable to 4, Start-up 5x8
- Highly efficient, easy-to-deploy 15kW, 400V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and 1 smart high-capacity modular battery string, expandable to 4 strings for extended runtime. Runtime charts available in the Documents tab.
- Includes: Battery modules ship installed, Dust filter, EcoStruxure Ready ((UPS)), Installation guide, Integrated network management, Power modules ship installed, Start-Up Service

Battery



Battery technology



Sealed Lead Acid (VRLA)


Battery voltage



480 V


Design



Certification



CSA C22.2 NO. 107.3, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IEC 60721-4-2 Level 2M2, UL 1778 5th edition


Display type



LCD


Form factor



Tower


International Protection (IP) code



IP20


Product colour



White


Features



Audible alarm(s)



Yes


Crest factor



2.5:1


ECO mode



Yes


Input current Total Harmonic Distortion (THD)



3 %


Input frequency



40/70 Hz


Input operation voltage (max)



460 V


Input operation voltage (min)



340 V


Input power factor



0.99


Maximum current



27 A


Noise level



55 dB


Number of input phases



3


Number of output phases



3


Output frequency



50/60 Hz


Output operation voltage (max)



415 V


Output operation voltage (min)



380 V


Output power



15000 Watt


Output power capacity



15 kVA


Output voltage Total Harmonic Distortion (THD)



3 %


Power protection features



Overload, Short circuit


UPS topology



Double-conversion (Online)


Waveform



Sine


Logistics data



Harmonized System (HS) code



85078000


Operational conditions



Non-operating altitude



0 - 3000 m


Operating altitude



0 - 1000 m


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-15 - 40 �C


Package dimensions



Depth (package,cm)



99 cm


Gross Weight (Package, kg)



0.13 kg


Height (package,cm)



168 cm


Width (package,cm)



64 cm


Packaging data



Quick installation guide



Yes


Ports & interfaces



AC outlet types



Hard Wire 3-wire (1PH + N + G), Hard Wire 4-wire (3PH + G)


SmartSlot



Yes


Product dimensions



Net Weight (Product, kg)



0.1 kg


Product Depth



84.7 cm


Product Height



148.5 cm


Product Width



52.1 cm


Vendor information



Brand Name


APC


Warranty



1 Year(s)
