APC SRT5KRMXLI-6W APC SMART-UPS SRT 5KVA 230V RM SRT5KRMXLI-6W

LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.

10/100 BaseT Connection
Connect the device to a network using a 10 or 100 BaseT connection

Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.

Scalable runtime
Allows additional run time to be quickly added as needed.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Network manageable
Provides remote power management of the UPS over the network.

InfraStruXure Manager Compatible
Enables centralized management via the APC InfraStruXure Manager.

SmartSlot
Customize UPS capabilities with management cards.

LED status indicators
Quickly understand unit and power status with visual indicators.

Serial connectivity
Provides management of the UPS via a serial port.

Plug-and-Play external batteries
Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.

Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Flash upgradeable firmware
Install maintenance releases of firmware remotely using FTP.

User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)

Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Predicitive failure notification
Provides early-warning fault analysis ensuring proactive component replacement.

Disconnected battery notification
Warns when a battery is not available to provide backup power.

Audible alarms
Provides notification of changing utility power and UPS power conditions

Frequency and voltage regulation
Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.

Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.

Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.

Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.

Cold-start capable
Provides temporary battery power when the utility power is out.

Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.

Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Battery



Automatic battery test



Yes


Battery capacity



845 VAh


Battery life (max)



5 year(s)


Battery recharge time



1.5 Hour


Battery technology



Sealed Lead Acid (VRLA)


Cold start



Yes


Hot-swap battery



Yes


Replacement battery cartridge



APCRBC140


Typical backup time at full load



4 min


Typical backup time at half load



11.8 min


Design



Certification



REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, NOM, VDE


Display



LCD


Display type



LCD


Energy Star certified



Yes


Form factor



Rackmount


International Protection (IP) code



IP20


Product colour



Black


Rack capacity



3U


RoHS compliance



Yes


Features



Audible alarm(s)



Yes


Auto-restart



Yes


Crest factor



3:1


Efficiency



94.1 %


Emergency Power Off (EPO)



Yes


Input frequency



40 - 70 Hz


Input operation voltage (max)



275 V


Input operation voltage (min)



160 V


Noise level



55 dB


Output frequency regulation



50/60 Hz


Output operation voltage (max)



240 V


Output operation voltage (min)



220 V


Output power



4500 Watt


Output power capacity



5 kVA


Output voltage Total Harmonic Distortion (THD)



3 %


Surge energy rating



480 J


Surge protection



Yes


UPS topology



Double-conversion (Online)


Waveform



Sine


Logistics data



Harmonized System (HS) code



85078000


Products per pallet



6 pc(s)


Operational conditions



Non-operating altitude



0 - 15000 m


Operating altitude



0 - 3000 m


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-15 - 45 �C


Other features



Packaging content



Web/SNMP Management Card


Package dimensions



Depth (package,cm)



96 cm


Gross Weight (Package, kg)



66.86 kg


Height (package,cm)



33 cm


Width (package,cm)



61 cm


Packaging data



Bracket



Yes


Quick installation guide



Yes


Rack mount kit



Yes


Temperature sensor



Yes


Warranty card



Yes


Ports & interfaces



AC outlet types



C13 coupler, C19 coupler


AC outlets quantity



10 AC outlet(s)


Number of output IEC jumpers



2


Power plug



Terminal


Serial interface



Yes


Serial interface type



RJ-45


SmartSlot



Yes


USB port



Yes


Product dimensions



Net Weight (Product, kg)



54.43 kg


Product Depth



71.9 cm


Product Height



13 cm


Product Width



43.2 cm


Technical details



Harmonized System (HS) code



85078000


Sustainability certificates



RoHS, ENERGY STAR


Vendor information



Brand Name


APC


Warranty



1 Year(s)
