APC SURT20KRMXLI Smart-UPS RT 20kVA RM 230V SURT20KRMXLI

APC Smart-UPS RT, 16 kW / 20 kVA,Input 230V / Output 230V, Interface Port DB-9 RS-232, RJ-45 10/100 Base-T, Smart-Slot, Extended runtime model, Rack Height 12 U.

Includes: CD with software, Rack Mounting support rails, Smart UPS signalling RS-232 cable, User Manual, Web/SNMP Management Card.

Battery



Automatic battery test



Yes


Battery capacity



3840 VAh


Battery life (max)



5 year(s)


Battery recharge time



2.5 Hour


Battery technology



Sealed Lead Acid (VRLA)


Cold start



Yes


Hot-swap battery



Yes


Typical backup time at full load



4.9 min


Typical backup time at half load



15.2 min


Design



Certification



BSMI, EN/IEC 62040-2, EN/IEC 62040-1-1, VDE, PEP, EOLI


Display type



LCD


Form factor



Rackmount/Tower


LED indicators



Y, Yes


Product colour



Black


Rack capacity



12U


Features



Audible alarm(s)



Yes


Auto-restart



Yes


Crest factor



3:1


Efficiency



93.7 %


Emergency Power Off (EPO)



Yes


Input frequency



40 - 70 Hz


Maximum current



115 A


Noise level



59 dB


Number of output phases



1


Output frequency regulation



50/60 Hz


Output operation voltage (max)



240 V


Output operation voltage (min)



220 V


Output power



16000 Watt


Output power capacity



20 kVA


Surge protection



Yes


UPS topology



Double-conversion (Online)


Waveform



Sine


Logistics data



Harmonized System (HS) code



85078000


Products per pallet



1 pc(s)


Operational conditions



Non-operating altitude



0 - 15000 m


Operating altitude



0 - 3000 m


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-15 - 45 �C


Other features



Nominal input voltage



230 V


Nominal output voltage



230 V


Packaging content



Web/SNMP Management Card


Package dimensions



Depth (package,cm)



100.3 cm


Gross Weight (Package, kg)



283.01 kg


Height (package,cm)



99 cm


Width (package,cm)



61 cm


Packaging data



Cables included



RS-232


Manual



Yes


Rack mount kit



Yes


Software CD



Yes


Ports & interfaces



AC outlet types



C19 coupler


AC outlets quantity



8 AC outlet(s)


Cabling technology



10/100Base-T


Ethernet LAN (RJ-45) ports



1


Number of output IEC jumpers



2


Power plug



Terminal


Serial interface



Yes


Serial interface type



RS-232


SmartSlot



Yes


Product dimensions



Net Weight (Product, kg)



283 kg


Product Depth



77.3 cm


Product Height



53.3 cm


Product Width



43.2 cm


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


APC


Homepage



http://www.apc.com/tools/ups_selector/


Warranty



2 Year(s)
