APC SURTD5000RMXLP3U Smart-UPS RT 5000VA RM 208V SURTD5000RMXLP3U

Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.

Scalable runtime
Allows additional run time to be quickly added as needed.

Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced

Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.

Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.

Battery



Battery recharge time



2.5 Hour


Battery technology



Sealed Lead Acid (VRLA)


Typical backup time at full load



4.8 min


Typical backup time at half load



15.1 min


Design



Cable length



3.05 m


Certification



CSA,FCC Part 15 Class A,UL 1778


LED indicators



Y, Yes


Product colour



Black


Features



Audible alarm(s)



Yes


Emergency Power Off (EPO)



Yes


Input frequency



50/60 Hz


Noise level



55 dB


Output power



4000 Watt


Output power capacity



5 kVA


Operational conditions



Non-operating altitude



0 - 15000 m


Operating altitude



0 - 3000 m


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



-15 - 45 �C


Other features



Dimensions (WxDxH)



432 x 660 x 130 mm


Input connection type



NEMA L14-30P


Interface



Smart-Slot


Nominal input voltage



208 V


Output voltage note



Configurable for 208 or 240 nominal output voltage


Package dimensions



Gross Weight (Package, kg)



58.06 kg


Product dimensions



Net Weight (Product, kg)



56.6 kg


Vendor information



Brand Name


APC


Warranty



1 Year(s)
