Arctic ACFAN00159A Bionix P140 Grey - ACFAN00159A

BioniX P140
Pressure-optimised 140 mm Gaming Fan with PWM PST

The BioniX P140 fan features completely redesigned fan blades and is optimised for high static pressure. Thus, the BioniX P140 is especially effective when used on heatsinks and with higher air resistance.
The wide RPM range from 200 to 1950 RPM can be regulated seamlessly and synchronously with other fans thanks to ARCTIC's PWM Sharing Technology (PST).
The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.

Design



Fan connector



4-pin + 4-pin


Number of fan blades



5


Number of fans



1 fan(s)


Product colour



Grey


Logistics data



Harmonized System (HS) code



84733080


Other features



Mounting hole pattern (W x D)



125 x 125 mm


Package dimensions



Depth (package,cm)



3.5 cm


Gross Weight (Package, kg)



0.26 kg


Height (package,cm)



14.8 cm


Width (package,cm)



14.8 cm


Packaging content



Number of screws



4


Package type



Box


Screws included



Yes


Performance



Airflow



131.92 m�/hr


Bearing type



Fluid Dynamic Bearing (FDB)


Compatible processor series



Not supported


Fan diameter



14 cm


Maximum air pressure



2.85 mmH2O


Maximum airflow



77.6 cfm


Noise level



0.45 sone


Pulse-width modulation (PWM) support



Yes


Rotational speed (max)



1950 RPM


Rotational speed (min)



200 RPM


Suitable location



Computer case


Supported processor sockets



Not supported


Type



Fan


Power



Power consumption (typical)



1.8 Watt


Rated current



0.15 A


Voltage



12 V


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



2.8 cm


Product Height



14 cm


Product Width



14 cm


Vendor information



Brand Name


Arctic


Warranty



1 Year(s)


Weight & dimensions



Cable length



0.4 m
