Asrock 90-MXB9G0-A0UAYZ Ab350M Pro4 R2.0 Amd B350 90-MXB9G0-A0UAYZ

BIOS



ACPI version



5.1


BIOS memory size



128 Mbit


BIOS type



UEFI AMI


System Management BIOS (SMBIOS) version



2.3


Expansion slots



Number of M.2 (M) slots



1


PCI Express x1 (Gen 2.x) slots



1


PCI Express x16 (Gen 2.x) slots



1


PCI Express x16 (Gen 3.x) slots



1


Features



Audio chip



Realtek ALC892


Audio output channels



7.1 channels


Certification



FCC, CE, WHQL, ErP/Eu


Component for



PC


Motherboard chipset



AMD B350


Motherboard chipset family



AMD


Motherboard form factor



micro ATX


PC health monitoring



CPU, Fan, Temperature, Voltage


Windows operating systems supported



Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64


Graphics



DirectX version



12.0


HDCP



Yes


Maximum resolution



4096 x 2160 Pixels


Internal I/O



12V power connector



Yes


ATX Power connector (24-pin)



Yes


CPU fan connector



Yes


Front panel audio connector



Yes


Number of chassis fan connectors



2


Number of COM connectors



1


Number of SATA III connectors



4


TPM connector



Yes


USB 3.2 Gen 1 (3.1 Gen 1) connectors



1


Logistics data



Harmonized System (HS) code



84733020


Memory



ECC



Yes


Maximum internal memory



64 GB


Memory channels



Dual-channel


Memory slots type



DIMM


Non-ECC



Yes


Number of memory slots



4


Supported memory clock speeds



2133, 2400, 2667, 2933, 3200


Supported memory types



DDR4-SDRAM


Unbuffered memory



Yes


Network



Ethernet interface type



Gigabit Ethernet


Ethernet LAN



Yes


LAN controller



Realtek RTL8111GR


Wake-on-LAN ready



Yes


Wi-Fi



No


Other features



Quick installation guide



Yes


Package dimensions



Gross Weight (Package, kg)



5.97 kg


Packaging content



Cables included



SATA


Drivers included



Yes


Processor



Compatible processor series



AMD A, AMD Athlon, AMD Athlon™ X4, AMD Ryzen™ 3, 2nd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 3, AMD Ryzen™ 5, 2nd Generation AMD Ryzen™ 5, 3rd Generation AMD Ryzen 5, AMD Ryzen™ 7, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9


Maximum number of SMP processors



1


Processor manufacturer



AMD


Processor socket



Socket AM4


Product dimensions



Net Weight (Product, kg)



4.59 kg


Product Depth



24.4 cm


Product Width



24.4 cm


Rear panel I/O ports



DVI-D ports quantity



1


Ethernet LAN (RJ-45) ports



1


HDMI ports quantity



1


HDMI version



1.4


PS/2 ports quantity



2


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



4


USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity



1


VGA (D-Sub) ports quantity



1


Storage controllers



Supported storage drive interfaces



SATA III


Vendor information



Brand Name


Asrock


Warranty



1 Year(s)
