Asrock Rx7600 Steel Legend 8Gb Oc Pcie4 8Gb Ddr6 Hdmi 3 Dp 2725Mhz Clock Overclo 90-GA4DZZ-00UANF

AMD Radeon RX 7600 Steel Legend 8GB OC



Boost Clock: Up to 2725 MHz / 18 Gbps
Game Clock: 2320 MHz / 18 Gbps
AMD Radeon™ RX 7600 GPU
8GB GDDR6 on 128-Bit Memory Bus
32 AMD RDNA™ 3 Compute Units (with RT+AI Accelerators)
32MB AMD Infinity Cache™ technology
Microsoft® DirectX® 12 Ultimate
PCI® Express 4.0 Support
1 x 8-pin Power Connector
3 x DisplayPort™ 2.1***, 1 x HDMI™ 2.1
Polychrome SYNC
Triple Fan Design
Stylish Metal Backplate
Striped Axial Fan
0dB Silent Cooling
Ultra-fit Heatpipe
Super Alloy Graphics Card
Polychrome Sync
Offers a comprehensive control to perform the built-in ARGB LEDs or the connected ARGB devices.


Triple Fan Design
Three fans for optimized cooling capacity



Stylish Metal Backplate
Stylish metal backplate makes the graphics card fancy, cool and solid.



Striped Axial Fan
ASRock’s brand-new fan design delivers enhanced air ow.



0dB Silent Cooling
Fans stop at low temperatures for complete silence.



Ultra-Fit Heatpipe
The heatpipes are consolidated to maximize the contact between them.




Super Alloy Graphics Card
Equipped with high quality components to maximize the performance and reliability.




Asrock Tweak 2.0
Users can easily customize their own favorite performance and smart fan settings.




8K Resolution Support
Supports next generation 8K video output for the ultimate visual experience.


DescriptionSpecification

Chipset Manufacturer: AMD
Interface: PCI Express 4.0
Graphics Chipset: AMD RX 7600
Memory Size: 8GB
Memory Type: DDR6
Memory Interface: 128-bit
Core Clock: Boost Clock: Up to 2725 MHz
Game Clock: 2320 MHz
Memory Clock: 18 Gbps
CUDA Cores / Stream Processors: 2048 Stream Processors
Outputs: 1 x HDMI 2.1
3 x DisplayPort 1.4
HDCP Support: Yes
Resolution: Digital Max Resolution: 7680 x 4320
DirectX Support: DirectX 12 Ultimate
Max Display Support: 4
Cooling: Triple Fan Design
Stylish Metal Backplate
Striped Axial Fan
0dB Silent Cooling
Ultra-fit Heatpipe
Super Alloy Graphics Card
PSU Requirements: 550W or greater recommended
Connectors Required: 1 x 8-pin PCIe power
Software: AMD Adrenalin Edition
Additional Features: See Overview
Dimensions: 303 x 131 x 45 mm
Slot Size: 2.5 Slot
Accessories: 1 x Quick Installation Guide
Package Type: Retail
#Hide#Lighting Effects: Yes
#Hide#HDMI: Yes (HDMI)
#Hide#DisplayPort: Yes (DisplayPort)
Package Weight: 1.6000 kg
Warranty: 2 Years
