Asus 90IG04Q0-MO3R10 RT-AX58U AX3000 AIMESH 90IG04Q0-MO3R10

AX3000 Dual Band WiFi 6 (802.11ax) Router supporting MU-MIMO and OFDMA technology, with AiProtection Pro network security powered by Trend Micro™, compatible with ASUS AiMesh WiFi system

Get Your Home Ready for WiFi 6 (802.11ax)
The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current Wi-Fi standard. The latest 802.11ax standard provides future-proof technologies, higher network efficiency, faster Wi-Fi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users.

Next-Gen WiFi Speed
RT-AX58U is a 2x2 dual-band Wi-Fi router that provides 160MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 3000Mbps — 574Mbps on the 2.4GHz band and 2402Mbps on the 5GHz band — RT-AX58U is 2.5X faster than 802.11ac 2x2 dual-band routers.

Built for Multi-device Households
With a revolutionary combination of OFDMA and MU-MIMO technology, 802.11ax technology provides up to 4X greater network capacity and efficiency in traffic-dense environments. Previous-generation 802.11ac Wi-Fi can only handle one device at a time on each network channel, which is an inefficient use of available bandwidth. OFDMA support in the 802.11ax Wi-Fi standard divides each channel into small sub-channels, allowing signals from multiple devices* to be bundled together and transmitted simultaneously, reducing latency for a smoother, more responsive Wi-Fi experience.

Commercial-grade Security for your Home Network
RT-AX58U has lifetime free AiProtection Pro, powered by Trend Micro™ with automatic, regularly updated security signatures to protect your devices and personal data from internet threats. This strong security offers advanced parental controls, including the ability to block specific websites and mobile app types.

The Latest WPA3 Network Security
The next generation of Wi-Fi security, bringing new capabilities to enhance Wi-Fi protections in personal and enterprise networks. Building on the widespread adoption of WPA2 over more than a decade, WPA3 adds new features to simplify Wi-Fi security, enable more robust authentication, and deliver increased cryptographic strength for highly sensitive data markets.

Powerful Whole-home Wi-Fi System.
The Way You Want.
In most cases, your RT-AX58U can deliver smooth, reliable Wi-Fi to every part of your home. But Wi-Fi coverage can be affected by many factors — room layout, construction materials, and even furnishings. ASUS AiMesh is an innovative new router feature that fixes these problems: it creates a whole-home Wi-Fi network using multiple ASUS routers. AiMesh is powerful, flexible and you can use a mix of ASUS router models — protecting your investment! AiMesh gives you time-saving central control, and seamless roaming capability. AiMesh is Wi-Fi you can rely on — for all your devices, all the time!

Antenna



Antenna design



External


Antenna type



External


Antennas quantity



4


Detachable antenna(s)



Yes


Design



LED indicators



LAN, Power, WAN


On/off switch



Yes


Features



Built-in processor



Yes


Flash memory



256 MB


Harmonized System (HS) code



85176990


Internal memory



512 MB


Processor frequency



1500 MHz


Logistics data



Harmonized System (HS) code



85176990


Management features



Reset button



Yes


Web-based management



Yes


WPS push button



Yes


Mobile network



3G



No


4G



No


Mobile network generation



4G


Network



Cabling technology



10/100/1000Base-T(X)


Ethernet LAN



Yes


Ethernet LAN data rates



10, 100, 1000


Ethernet LAN interface type



Gigabit Ethernet


Networking standards



IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n


VPN support



IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client


Other features



Frequency range



2.4 - 5 GHz


Transmission encryption



Yes


Package dimensions



Gross Weight (Package, kg)



0.538 kg


Packaging content



AC adapter included



Yes


Cables included



AC


Packaging data



AC adapter included



Yes


Cables included



AC


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Memory card slot(s)



No


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



1


USB port



Yes


Power



AC input frequency



50 - 60 Hz


AC input voltage



110 - 240 V


Output current



1.75 A


Output voltage



19 V


Power source type



AC, DC


Product dimensions



Net Weight (Product, kg)



0.43800000000000006 kg


Product Depth



22.4 cm


Product Height



16 cm


Product Width



15.4 cm


Protocols



Management protocols



UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log


Security



Firewall



Yes


Firewall security



SPI intrusion detection, DoS protection


Security algorithms



WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPS


System requirements



Mac operating systems supported



Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion


Windows operating systems supported



Windows 10, Windows 7, Windows 8


Vendor information



Brand Name


Asus


Warranty



1 Year(s)


WAN connection



3G/4G USB modem compatibility



No


DSL WAN



No


Ethernet WAN



Yes


SIM card slot



No


WAN connection type



RJ-45


Wireless LAN features



Top Wi-Fi standard



Wi-Fi 6 (802.11ax)


Wi-Fi band



Dual-band (2.4 GHz / 5 GHz)


Wi-Fi standards



802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)


WLAN data transfer rate (max)



2402 Mbit/s
