Asus 90MB1B70-M0EAY0 Rog Strix X670E-I Gaming Wifi 90MB1B70-M0EAY0

BIOS



BIOS memory size



256 Mbit


BIOS type



UEFI AMI


Expansion slots



Number of M.2 (M) slots



2


PCI Express x16 (Gen 5.x) slots



1


Features



Audio chip



Realtek ALC4050H


Component for



PC


Motherboard chipset



AMD X670


Motherboard chipset family



AMD


Motherboard form factor



mini ITX


Windows operating systems supported



Windows 10 x64, Windows 11 x64


Graphics



Maximum resolution



3840 x 2160 Pixels


Internal I/O



ATX Power connector (24-pin)



Yes


CPU fan connector



Yes


EPS power connector (8-pin)



Yes


Front panel audio connector



Yes


Number of chassis fan connectors



1


Number of SATA III connectors



2


USB 2.0 connectors



2


USB 3.2 Gen 1 (3.1 Gen 1) connectors



1


USB 3.2 Gen 2 (3.1 Gen 2) connectors



1


Memory



ECC



Yes


Maximum internal memory



64 GB


Memory channels



Dual-channel


Memory slots type



DIMM


Non-ECC



Yes


Number of memory slots



2


Supported memory clock speeds



4800, 5000, 5200, 5400, 5600, 5800, 6000, 6200, 6400


Supported memory types



DDR5-SDRAM


Unbuffered memory



Yes


Network



Bluetooth



Yes


Bluetooth version



5.2


Ethernet interface type



2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet


Ethernet LAN



Yes


LAN controller



Intel I225-V


Top Wi-Fi standard



Wi-Fi 6E (802.11ax)


Wi-Fi



Yes


Wi-Fi standards



802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)


Other features



Weight



870 g


Package dimensions



Depth (package,cm)



11 cm


Gross Weight (Package, kg)



1.3 kg


Height (package,cm)



22 cm


Width (package,cm)



28.5 cm


Processor



Processor manufacturer



AMD


Processor socket



Socket AM5


Product dimensions



Net Weight (Product, kg)



1 kg


Product Depth



17 cm


Product Width



17 cm


Rear panel I/O ports



Ethernet LAN (RJ-45) ports



1


HDMI ports quantity



1


USB 2.0 ports quantity



3


USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity



5


USB4 Gen 3x2 ports quantity



2


Storage controllers



Number of storage drives supported



4


Supported storage drive interfaces



M.2, SATA III


Supported storage drive types



HDD & SSD


Vendor information



Brand Name


Asus


Warranty



1 Year(s)
