Asus PRIME B760M-A WIFI Socket 1700/B760/Ddr5/S-Ata 6Gb/S/Micro Atx PRIME B760M-A WIFI

ASUS 1700 PRIME B760M-A WIFI M-ATX
SKU: 123608
Product Group:Motherboards
Manufacturer:ASUS
SKU:123608
Product Name:ASUS PRIME B760M-A WIFI (Socket 1700/B760/DDR5/S-ATA 6Gb/s/Micro ATX)
Web Address:www.asus.com
Model Number:PRIME B760M-A WIFI
EAN:4711387131435
UPC:197105131439
Package Type:Retail
Warranty:3 Years
BIOS:128 Mb Flash ROM
UEFI AMI BIOS

Chipset:Intel B760
CPU Interface:Socket 1700
CPU Support:https://www.asus.com/uk/motherboards-components/motherboards/prime/prime-b760m-a-wifi/helpdesk_qvl_cpu/?model2Name=PRIME-B760M-A-WIFI
RAM Technology:DDR5 (Dual Channel)
RAM Slots:4 x 288-pin
RAM Speeds:Up to DDR5 7200+ (O.C.)
Max. Memory Support:128GB
PCI Express 4.0 x16:3
S-ATA 6Gb/s Port(s):4
RAID:Raid 0/1/5/10
M.2 Socket(s):2 x PCIe Gen 4.0 x4
On-Board LAN:1 x Realtek 2.5Gb Ethernet
Wireless NIC:Wi-Fi 6
Wireless Technology:2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band

Bluetooth:v5.2
On-Board Audio:Realtek 7.1 Surround Sound High Definition Audio CODEC
On-Board Video:Processor with integrated graphics is required
Back PS/2 Keyboard/Mouse Port:1
Back USB 2.0 Port(s):4
Back USB 3.2 Port(s) Type-A Gen 2:2
Back HDMI Port(s):2
Back DisplayPort(s):1
Back LAN Port(s):1
Back Audio Jack(s):3
Back Other Port(s):1 x Wi-Fi Module
24-pin ATX Power:1
8-pin ATX Power:1
USB 2.0 Header(s):3
USB 3.2 Header(s) Gen 1:3
Parallel Port Header(s):1
COM Port Header(s):1
Front Panel Audio Connector:1
TPM Header(s):1
S/PDIF Out Header(s):1
Internal Other Port(s):3 x Addressable Gen 2 headers
1 x Aura RGB header

Form Factor:Micro ATX
Product Width:244mm
Product Length:244mm
Package Width:27.5cm
Package Length:27.8cm
Package Height:6.7cm
Gross Weight:1.48Kg
Special Features:Intel LGA 1700 Socket: Ready for 13th and 12th Gen Intel processors.
Ultrafast Connectivity: PCIe 4.0, two M.2 slots, Realtek 2.5Gb Ethernet, Wi-Fi 6, rear USB 3.2 Gen 2, front USB 3.2 Gen 1 Type-C.
Comprehensive Cooling: VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+.
Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II.
Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware.

Package Contents:Motherboard
2 x SATA 6Gb/s Cables
1 x ASUS Wi-Fi Moving Antennas
1 x I/O Shield
1 x M.2 Rubber Package
1 x Screw Package for M.2 SSD
1 x User Guide
