Asus TUF GAMING B860M-PLUS WIFI Socket 1851/B860/Ddr5/S-Ata 6Gb/S/Micro Atx TUF GAMING B860M-PLUS WIFI

Product Group:

Motherboards



Manufacturer:

ASUS



SKU:
6204


Product Specifications



Product Name:

ASUS TUF GAMING B860M-PLUS WIFI (Socket 1851/B860/DDR5/S-ATA 6Gb/s/Micro ATX)



Web Address:

www.asus.com



Model Number:

TUF GAMING B860M-PLUS WIFI



EAN:

4711387783092



UPC:
7105783096



Package Type:

Retail



Warranty:

3 Years



BIOS:

2 x 128 Mb Flash ROM, UEFI AMI BIOS



Chipset:

Intel B860



CPU Interface:

Socket 1851



CPU Support:

https://www.asus.com/motherboards-components/motherboards/tuf-gaming/tuf-gaming-b860m-plus-wifi/helpdesk_qvl_cpu?model2Name=TUF-GAMING-B860M-PLUS-WIFI



RAM Technology:

DDR5 (Dual Channel)



RAM Slots:

4 x 288-pin



RAM Speeds:

Up to DDR5 8800 (O.C.)



Max. Memory Support:

256GB



PCI Express 5.0 x16:

1



PCI Express 4.0 x4:

1



S-ATA 6Gb/s Port(s):

4



RAID:

Raid 0/1/5/10



M.2 Socket(s):

1 x PCIe Gen 5.0 x4
2 x PCIe Gen 4.0 x4



LAN Speed:

1 x Realtek 2.5Gb Ethernet
TUF LANGuard



Wireless NIC:

Wi-Fi 7



Wireless Technology:

2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.



Bluetooth:

v5.4



On-Board Audio:

Realtek 7.1 Surround Sound High Definition Audio CODEC



On-Board Video:

Processor with integrated graphics is required



Back USB 2.0 Port(s):

1



Back USB 5Gbps Port(s) Type-A:

4



Back USB 10Gbps Port(s) Type-A:

2



Back USB 20Gbps Port(s) Type-C:

1



Back HDMI Port(s):

1



Back DisplayPort(s):

1



Back LAN Port(s):

1



Back Audio Jack(s):

5



Back S/PDIF Output Port(s):

1



Back Other Port(s):

1 x Wi-Fi Module



24-pin ATX Power:

1



8-pin ATX Power:

2



USB 2.0 Header(s):

1



USB 5Gbps Header(s):

1



USB 10Gbps Header(s):

1



Thunderbolt Header(s):

1



Front Panel Audio Connector:

1



Internal Other Port(s):

3 x Addressable Gen 2 headers



Form Factor:

Micro ATX



Product Width:

244mm



Product Length:

244mm



Package Width:

27.5cm



Package Length:

27.5cm



Package Height:

7cm



Gross Weight:

1.68Kg



Special Features:

ASUS TUF GAMING B860M-PLUS WIFI takes all the essential elements of the latest Intel Core Ultra Processors (Series 2) and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. This platform delivers the power and connectivity that advanced AI PC applications demand.



Package Contents:

Motherboard
2 x SATA 6Gb/s cables
1 x ASUS WiFi Q-Antenna
2 x M.2 Rubber Packages
1 x TUF Gaming sticker
1 x Screw package for M.2 SSD
1 x Quick start guide
