ATEN 2 Port True 4K HDMI Splitter HDMI 2x HDMI 4096 x 2160 pixels Black Aluminiu VS82H

The ATEN VS82H splitter offers you superior video resolution of True 4K and lossless quality when sending one source of digital high-definition video to two displays. It supports HDMI-enabled equipments from DVD players, satellite set-top boxes to all HDMI displays.

Aside from being HDCP 2.2 compliant, the VS82H comes with automatic EDID detection that always presents users with the best resolution across different screens. Along with support for Dolby TrueHD and DTS-HD Master 7.1 Audio channel, the VS82H ensures you distortionless and outstanding audio quality.

What's more, the VS82H is a bus-powered splitter that can be charged directly from a device connected through Micro-USB port. Integrating the above functionalities provides you an effective solution for personal, corporate, educational and commercial applications.

Features


Distributes one True 4K source to two HDMI displays at the same time


Automatic downscaling function - automatically adjusts the resolution to 1080p for 1080p displays to fit their optimal output


HDMI 2.0 (3D, Deep Color, 4K); HDCP 2.2 compliant


True 4K video resolution (up to 4096 x 2160 @ 60 Hz; 4:4:4); HDR supported


Supports max. data rate up to 18 Gbps (6 Gbps Per Lane)


Supports Dolby TrueHD and DTS-HD Master 7.1 Audio channel


Automatic EDID detection - enjoy high-quality display and use of the best resolution across different screens


Quality and durable aluminum metal enclosure



Weight & dimensions


Height

88 mm


Width

60 mm


Depth
0 mm


Weight
0 g



Packaging content


Cables included

Micro-USB


Manual

Yes



Logistics data


Master (outer) case width

315 mm


Master (outer) case height

338 mm


Products per master (outer) case

40 pc(s)


Harmonized System (HS) code

85176990


Master (outer) case length

490 mm


Master (outer) case net weight

4.8 kg


Master (outer) case gross weight

8.36 kg



Features


3D

Yes


Maximum operating distance

5 m


Maximum resolution

4096 x 2160 pixels


Maximum refresh rate

60 Hz


Product colour

Black


Bandwidth

600 MHz


Housing material

Aluminium


Dolby technologies

DTS-HD Master Audio, Dolby TrueHD


HD type

4K Ultra HD


HDCP version

2.2


LED indicators

Status



Operational conditions


Operating temperature (T-T)

0 - 40 -C


Operating relative humidity (H-H)

0 - 80


Storage relative humidity (H-H)

0 - 80


Storage temperature (T-T)

-20 - 60 -C



Ports & interfaces


Video out

2x HDMI


Video ports quantity

2


Video port type

HDMI


HDMI version

2.0



Power


AC input voltage

5 V


USB powered

Yes


Power consumption (typical)

1.35 W



Packaging data


Package height
0 mm


Quantity per pack

1 pc(s)


Package depth
9 mm


Package width

59 mm


Package weight
6 g
