Chieftec BBS-700S Power Supply Unit 700 W BBS-700S

With the Core Series, Chieftec will be bringing a new 80 PLUS Gold certified PSU to market, offering the best possible value-formoney. The goal of the Core Series power-supplies is to deliver a no-nonsense package of performance, efficiency and reliability. With power output ranging from 500W to 700W, this product is idea for customers who want top-tier power output at the most attractive price.

Design



Cooling type



Active


Fan diameter



12 cm


Number of fans



1 fan(s)


Product colour



Black


Logistics data



Harmonized System (HS) code



84733020


Package dimensions



Gross Weight (Package, kg)



2.24 kg


Performance



80 PLUS certification



80 PLUS Gold


Power supply unit (PSU) form factor



PS/2


Purpose



PC


Ports & interfaces



CPU power cable length



65 cm


CPU power connector (4+4 pin)



Yes


Floppy disk drive connector



Yes


Floppy drive power connector



1


Motherboard power connector



24-pin ATX


Number of SATA power connectors



6


PCI Express power cable length



50 cm


PCI Express power connectors (6+2 pin)



4


Peripheral (Molex) power cable length



150, 500


Peripheral (Molex) power connectors (4-pin)



3


SATA power cable length



150, 500


Power



AC input frequency



47 - 63 Hz


AC input voltage



100 - 240 V


Combined power (+5Vsb)



12.5 Watt


Combined power (-12V)



3.6 Watt


Input current



10 A


Max output current (+12V1)



58 A


Max output current (+3.3V)



22 A


Max output current (+5V)



22 A


Max output current (+5Vsb)



2.5 A


Max output current (-12V)



0.3 A


Power Factor Correction (PFC) type



Active


Power protection features



Over voltage, Overload, Short circuit


Total power



700 Watt


Product dimensions



Net Weight (Product, kg)



1.72 kg


Product Depth



15 cm


Product Height



8.6 cm


Product Width



14 cm


Vendor information



Brand Name


Chieftec


Warranty



1 Year(s)
