Chieftec CSN-450C Power Supply Unit 450 W 20+4 CSN-450C

Design



Cooling type



Active


Fan diameter



8 cm


Fan location



Top


Number of fans



1 fan(s)


Product colour



Black


Logistics data



Harmonized System (HS) code



84733020


Other features



Parallel processing technology support



CrossFire, CrossFireX, SLI


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



80 PLUS certification



80 PLUS Gold


ATX version



2.3


Power supply unit (PSU) form factor



SFX


Purpose



PC


Ports & interfaces



ATX power connector (20+4 pin)



Yes


Cabling type



Modular


CPU power connector (4+4 pin)



Yes


Floppy disk drive connector



Yes


Floppy drive power connector



1


Motherboard power connector



20+4 pin ATX


Number of SATA power connectors



6


PCI Express connector



Yes


PCI Express power connectors (6+2 pin)



2


Peripheral (Molex) power connectors (4-pin)



3


Power



AC input frequency



47 - 63 Hz


AC input voltage



100 - 240 V


Combined power (+12V)



450 Watt


Combined power (+3.3V)



90 Watt


Combined power (+5V)



90 Watt


Efficiency



90 %


Input current



6 A


Max output current (-12V)



0.3 A


Max output current (+12V1)



37.5 A


Max output current (+3.3V)



18 A


Max output current (+5V)



15 A


Max output current (+5Vsb)



3 A


Power factor



0.9


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage


Total power



450 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



12.5 cm


Product Height



6.4 cm


Product Width



10 cm


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Chieftec


Warranty



1 Year(s)
