Chieftec GDP-550C A-90 550W retail 80 Plus Gold GDP-550C

Efficiency at low cost, that�s the reason, why the new A-90 series from CHIEFTEC has been invented. The three high performance PSU�s cover with their nominal power output of 550 watts � 750 watts all kinds of usage possibilities. With a fixed output voltage of 230 V, this power supply series is especially made for cost-aware computer consumers. The PSU�s have an efficiency of >90% and thus meet the 80plus gold requirements.

Design



Fan diameter



14 cm


Product colour



Black


Logistics data



Harmonized System (HS) code



84733020


Package dimensions



Gross Weight (Package, kg)



1 kg


Performance



ATX version



2.3


Power supply unit (PSU) form factor



PS/2


Purpose



PC


Ports & interfaces



CPU power connector (4+4 pin)



Yes


Floppy drive power connector



1


Motherboard power connector



20+4 pin ATX


Number of SATA power connectors



6


PCI Express power connectors (6+2 pin)



2


Peripheral (Molex) power connectors (4-pin)



3


Power



AC input frequency



47 - 63 Hz


AC input voltage



200 - 240 V


Combined power (+3.3V)



110 Watt


Combined power (+5V)



110 Watt


Input current



4 A


Max output current (+12V1)



45 A


Max output current (+3.3V)



20 A


Max output current (+5V)



20 A


Max output current (+5Vsb)



2.5 A


Max output current (-12V)



0.3 A


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage


Total power



550 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



16 cm


Product Height



8.7 cm


Product Width



15 cm


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Chieftec


Warranty



1 Year(s)
