Chieftec GPU-1200FC Power Supply Unit 1200 W 20+4 GPU-1200FC

The Chieftronic PowerPlay series builds on Chieftec�s many years of experience developing top-quality power-supplies and combines top specs like 80 PLUS Gold (at 550W, 650W, 750W) and 80 PLUS Platinum (at 850W, 1050W), premium Japanese capacitors for low ripple noise with an eye-catching fan filter design to offer an attractive PSU for users who want a true top-tier product.

Featuring a rugged build quality, the PowerPlay series measures only 160mm in length, therefore comfortably fitting into almost any system supporting ATX format PSU�s and leaving plenty of space for easy cable management.

This combination of efficiency, performance and build design makes the PowerPlay series a true top-of-the-line model leading Chieftronic�s PSU line-up.

Design



Cooling type



Active


Fan diameter



14 cm


Fan location



Top


Number of fans



1 fan(s)


On/off switch



Yes


Product colour



Black, Red


Logistics data



Harmonized System (HS) code



84733020


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



80 PLUS certification



80 PLUS Gold


ATX version



2.53


Power supply unit (PSU) form factor



ATX


Purpose



PC/Server


Ports & interfaces



ATX power connector (20+4 pin)



Yes


ATX Power connector (24-pin)



No


Cabling type



Modular


EPS power connector (4+4 pin)



Yes


Floppy drive power connector



1


Motherboard power cable length



60 cm


Motherboard power connector



20+4 pin ATX


Number of SATA power connectors



9


PCI Express connector



Yes


PCI Express power cable length



60 cm


PCI Express power connectors (6+2 pin)



8


Peripheral (Molex) power cable length



150, 700


Peripheral (Molex) power connectors (4-pin)



3


SATA power cable length



150, 500


Power



AC input frequency



47 - 63 Hz


AC input voltage



100 - 240 V


Combined power (+12V)



1200 Watt


Combined power (+3.3V)



130 Watt


Combined power (+5V)



130 Watt


Combined power (+5Vsb)



15 Watt


Combined power (-12V)



3.6 Watt


Input current



14 A


Max output current (+12V)



100 A


Max output current (+3.3V)



25 A


Max output current (+5V)



25 A


Max output current (+5Vsb)



3 A


Max output current (-12V)



0.3 A


Power factor



0.9


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage


Total power



1200 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



16 cm


Product Height



8.6 cm


Product Width



15 cm


Technical details



Sustainability certificates



CE


Sustainability compliance



Yes


Vendor information



Brand Name


Chieftec


Warranty



1 Year(s)
