Cisco AIR-AP1815I-E-K9-RFB AP/Aironet 1815i Series AIR-AP1815I-E-K9-RFB

The Cisco Aironet 1815i delivers industry-leading wireless performance with support for the latest Wi-Fi standard, IEEE�s 802.11ac Wave 2 (Figure 1). It also meets the growing requirements of wireless networks by delivering a better user experience.

The 1815i extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support.

By adhering to the 802.11ac Wave 2 standard, the 1815i offers a data rate of up to 867 Mbps on the 5-GHz radio. This exceeds the data rates offered by access points that support the 802.11n standard. It also enables a total aggregate dual-radio data rate of up to 1 Gbps. This provides the necessary foundation for enterprise and service provider networks to stay ahead of the performance expectations and needs of their wireless users.

Due to its convenience, in recent years corporate users have increasingly preferred wireless access as the form of network connectivity. Along with this shift, there is an expectation that wireless should not slow down users� day-to-day work, but should enable a high-performance experience while allowing users to move freely. The 1815i delivers industry-leading performance for highly secure and reliable wireless connections and provides a robust mobility end-user experience. Table 1 lists the features and benefits of the 1815i.

Antenna



Antenna gain level (max)



4 dBi


Antenna type



Internal


Design



Internal



No


LED indicators



Y, Yes


Placement



Table


Product colour



White


Features



2.4 GHz



Yes


5 GHz



Yes


Channels quantity



29 channels


Ethernet LAN data rates



10, 100, 1000


Frequency band



2.412 - 2.472, 5.18 - 5.32, 5.5 - 5.6, 5.64 - 5.7 GHz


Maximum data transfer rate



1000 Mbit/s


Maximum data transfer rate (5 GHz)



867 Mbit/s


Networking standards



IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u


Transmitting power



4 dBmW


VLAN support



Yes


Wi-Fi Multimedia (WMM)/(WME)



Yes


Logistics data



Harmonized System (HS) code



85176990


Quantity per pack



1 pc(s)


Operational conditions



Non-operating altitude



0 - 4500 m


Operating altitude



0 - 3000 m


Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



10 - 90 %


Storage temperature (T-T)



-30 - 70 �C


Package dimensions



Depth (package,cm)



23.98 cm


Gross Weight (Package, kg)



0.8 kg


Height (package,cm)



6.98 cm


Width (package,cm)



22.07 cm


Performance



Built-in processor



Yes


Flash memory



256 MB


Internal memory



1024 MB


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Power



Power over Ethernet (PoE)



Yes


Product dimensions



Net Weight (Product, kg)



0.7000000000000001 kg


Product Depth



15.08 cm


Product Height



3.3 cm


Product Width



15.08 cm


Security



Remote Authentication Dial-In User Service (RADIUS)



Yes


Security algorithms



802.1x RADIUS, AES, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA, WPA2


Technical details



Harmonized System (HS) code



85176990


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)
