Cisco AIR-AP4800-E-K9 Aironet 4800 5200 Mbit/S AIR-AP4800-E-K9

The Cisco Aironet 4800 Access Point is packed with an abundance of features that offer users a better experience, top-notch security, and high-speed connectivity. The Aironet� 4800 makes troubleshooting easier and enhances the context shown in Cisco DNA� Assurance.

The access point�s functionality is spread out over four internal radios, so these features run simultaneously over your network. The Aironet 4800 expands the current rich capabilities of our current Aironet portfolio (with features such as built-in Flexible Radio Assignment, Hyperlocation, and Bluetooth Low Energy [BLE]) and adds a fourth internal radio to provide rich performance and location and security analytics. With more radios embedded in the access point, your wireless network achieves higher security and data analysis without degrading performance�you�ll never again have to trade security for network performance.

What does this mean?
For starters, having a fourth radio allows the BLE and security monitoring functions to run on their own individual radios, while the other two radios tend to the business of providing exceptional Wi-Fi. This level of visibility provides IT more powerful capabilities to help ensure the user experience for productivity and engagement.

Antenna



Antenna gain level (max)



5 dBi


Antenna type



Internal


Design



Cable lock slot



Yes


Certification



UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1, EN 50155


LED indicators



Y, Yes


Placement



Ceiling, Wall


Product colour



White


Features



2.4 GHz



Yes


5 GHz



Yes


Channel bandwidth



160 MHz


Channels quantity



29 channels


Cyclic Shift Diversity (CSD)



Yes


Data unit aggregation



A-MSDU, A-MPDU


Dynamic Frequency Selection (DFS)



Yes


Ethernet LAN data rates



100, 1000, 2500, 5000


Frequency band



2.412 - 2.472, 5.18 - 5.32, 5.5 - 5.7 (excludes 5.6 - 5.64) GHz


Maximal-Ratio Combining (MRC)



Yes


Maximum data transfer rate



5200 Mbit/s


MIMO



Yes


MIMO type



Multi User MIMO


Networking standards



IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3bz


Transmitting power



23 dBmW


Wi-Fi Multimedia (WMM)/(WME)



Yes


Logistics data



Harmonized System (HS) code



85176990


Management features



Firmware upgradeable



Yes


Syslog



Yes


Web-based management



Yes


Operational conditions



Non-operating altitude



0 - 4572 m


Operating altitude



0 - 3000 m


Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



-30 - 70 �C


Package dimensions



Gross Weight (Package, kg)



3.25 kg


Packaging content



Number of products included



1 pc(s)


Performance



Flash memory



256 MB


Internal memory



1024 MB


Ports & interfaces



Ethernet LAN (RJ-45) ports



2


USB 2.0 ports quantity



1


Power



Power over Ethernet (PoE)



Yes


Power supply



50 Watt


Product dimensions



Net Weight (Product, kg)



2.5 kg


Product Depth



25 cm


Product Height



7.35 cm


Product Width



22 cm


Security



Security algorithms



AES, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, TKIP, WPA, WPA2


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)
