Cisco CBS220-24P-4G-EU Cbs220-24P-4G Managed L2 CBS220-24P-4G-EU

Simple, affordable business networking
The Cisco Business 220 Series Smart Switches are simple and affordable smart switches for business-class networks. With their intuitive dashboard, mobile app support, and multiple Power over Ethernet (PoE) options, these switches deliver a solid business network.

Cisco Small Business Support Service
Get software updates, extended access to the Cisco Small Business Support Center, and expedited hardware replacement if you need it. The Cisco Small Business Support Service helps you protect your investment and get added value from Cisco Business products. The service is delivered by Cisco and backed by your Cisco partner.

Small business networking solutions
Operate your network with simple, flexible, and highly secure solutions specifically designed for the small business.

Data transmission



Forwarding rate



41.66 Mpps


Jumbo frames



9216


Jumbo frames support



Yes


MAC address table



8192 entries


Number of queues



8


Packet buffer memory



4.1 MB


Switching capacity



56 Gbit/s


Design



Form factor



1U


LED indicators



Y, Yes


Number of fans



1 fan(s)


Product colour



White


Rack mounting



Yes


Reset button



Yes


Logistics data



Harmonized System (HS) code



85176990


Management features



Quality of Service (QoS) support



Yes


Switch layer



L2


Switch type



Managed


System event log



Yes


Web-based management



Yes


Multicast features



Multicast MAC address table



8192 entries


Multicast support



Yes


Network



10G support



Yes


Auto MDI/MDI-X



Yes


Broadcast storm control



Yes


Ethernet LAN data rates



10, 100, 1000


Flow control support



Yes


Head-of-line (HOL) blocking



Yes


IP routing



Yes


Link aggregation



Yes


Networking standards



IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z


Number of VLANs



256


Port mirroring



Yes


Spanning tree protocol



Yes


VLAN support



Yes


Operational conditions



Heat dissipation



833.59 BTU/h


Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 50 �C


Storage relative humidity (H-H)



10 - 90 %


Storage temperature (T-T)



-20 - 70 �C


Package dimensions



Gross Weight (Package, kg)



5.29 kg


Performance



Built-in processor



Yes


Firmware upgradeable



Yes


Flash memory



64 MB


Internal memory



256 MB


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


SFP module slots quantity



4


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Power over Ethernet (PoE)



Power over Ethernet (PoE)



Yes


Product dimensions



Net Weight (Product, kg)



4.07 kg


Product Depth



20.3 cm


Product Height



4.4 cm


Product Width



44 cm


Protocols



GARP VLAN Registration Protocol (GVRP)



Yes


Management protocols



SNMP v1/2c/3, Telnet, TFTP, HTTP/HTTPS, SNTP


Security



Access Control List (ACL)



Yes


Authentication type



IEEE 802.1x, RADIUS


BPDU filtering/protection



Yes


DHCP features



DHCP client


IGMP snooping



Yes


Loop protection



Yes


MAC address filtering



Yes


Queue scheduling algorithms



Weighted Round Robin (WRR)


Security algorithms



SSH, SSH-2, SSL/TLS


SSH/SSL support



Yes


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)
