Cisco CBS250-24FP-4X-EU Network Switch Managed L2/L3 CBS250-24FP-4X-EU

In today's hyperconnected world, reliable access to network resources is critical to all businesses. However, you also need to invest wisely to stay competitive, knowing how to separate the essential from the extraneous and get the most value for your dollar. While building a solid foundation for your business network infrastructure is essential, it doesn�t mean you need the most advanced feature set on the market.

For businesses requiring high performance, advanced security, and rich manageability from the network, fully managed switches are an excellent choice. However, they also typically come with high price tags. Smart switches provide the right level of network features and capabilities for growing businesses at an affordable price, so you�ll have more dollars to put toward growing your business.

With Cisco� Business 250 Series Smart Switches, you can achieve enterprise-grade network performance and security without paying for advanced network features that you will not use. When you need a reliable solution to share online resources and connect computers, phones, and wireless access points, Cisco Business 250 Series Smart Switches provide the ideal solution at an affordable pricing point.

The Cisco Business 250 Series is the next generation of affordable smart switches that combine powerful network performance and reliability with a complete suite of the network features you need for a solid business network. These powerful Gigabit Ethernet switches, with Gigabit or 10 Gigabit Ethernet uplinks, provide multiple management options, sophisticated security capabilities, and fine-tuned Quality of Service (QoS) and Layer 3 static routing features far beyond those of an unmanaged or consumer-grade switch, at a lower cost than for fully managed switches. And with an easy-to-use web user interface and Power over Ethernet Plus (PoE+) capability, you can deploy and configure a complete business network in minutes.

Data transmission



Jumbo frames



9000


Jumbo frames support



Yes


MAC address table



8000 entries


Design



LED indicators



Y, Yes


Product colour



Silver


Rack mounting



Yes


Reset button



Yes


Logistics data



Harmonized System (HS) code



85176990


Management features



ARP inspection



Yes


Cloud-managed



Yes


Configuring Location Settings (CLI)



Yes


MIB support



Y


Quality of Service (QoS) support



Yes


Switch layer



L2/L3


Switch type



Managed


Web-based management



Yes


Multicast features



Multicast support



Yes


Network



Auto MDI/MDI-X



Yes


Broadcast storm control



Yes


Ethernet LAN data rates



1000


Flow control support



Yes


Head-of-line (HOL) blocking



Yes


Networking standards



IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1af, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u


Number of VLANs



255


Port mirroring



Yes


Spanning tree protocol



Yes


VLAN support



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



-5 - 50 �C


Storage relative humidity (H-H)



10 - 90 %


Storage temperature (T-T)



-25 - 70 �C


Package dimensions



Gross Weight (Package, kg)



5.98 kg


Performance



Built-in processor



Yes


Firmware upgradeable



Yes


Flash memory



256 MB


Internal memory



512 MB


Processor frequency



800 MHz


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


SFP+ module slots quantity



4


USB 2.0 ports quantity



1


Power



AC input frequency



50 - 60 Hz


Power supply included



Yes


Product dimensions



Net Weight (Product, kg)



4.6 kg


Protocols



Management protocols



SNMP


Security



Access Control List (ACL)



Yes


Access Control List (ACL) rules



512


DHCP features



DHCP relay, DHCPv6 client


IGMP snooping



Yes


MAC address filtering



Yes


Password protection



Yes


Security algorithms



HTTPS, SSH, SSL/TLS


SSH/SSL support



Yes


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)
