Cisco MX68CW-HW-WW Meraki Mx68Cw-Hw Hardware MX68CW-HW-WW

All in one Wireless, LTE, Security, and SD-WAN

Hardware
- Stateful firewall throughput: 450 Mbps
- Recommended maximum clients: 50
- Small form factor
- 2 PoE+ ports

Wireless
- Dual-band, dual-concurrent: 2.4 & 5 GHz
- 2-stream 802.11ac Wave 2 and 802.11n, up to 1.3Gbps
- Supports up to 4 SSIDs

Cloud-based centralized management
- Managed centrally over the web
- Classifies applications, users and devices
- Zero-touch, self-provisioning deployments

Networking and security
- Stateful firewall
- Auto VPN� self-configuring site-to-site VPN
- Active Directory integration
- Identity-based policies
- Client VPN (IPsec)
- 3G / 4G failover via CAT 6 LTE or USB modem

Traffic shaping and application management
- Layer 7 application visibility and traffic shaping
- Application prioritization

Advanced security services
- Content filtering
- Google SafeSearch and YouTube for Schools
- Intrusion detection & prevention (IDS/IPS)
- Advanced Malware Protection (AMP)
- Cisco Threat Grid

Data transmission



Firewall throughput



450 Mbit/s


VPN throughput



200 Mbit/s


Design



Form factor



Desktop


Logistics data



Harmonized System (HS) code



85176990


Management features



LED indicators



Y, Yes


Network



Number of users



50 user(s)


VPN tunnels quantity



50


Wi-Fi



Yes


Wi-Fi standards



Wi-Fi 5 (802.11ac)


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 40 �C


Package dimensions



Gross Weight (Package, kg)



4.69 kg


Performance



Antennas quantity



2


Ports & interfaces



Connectivity technology



Wired & Wireless


Ethernet LAN (RJ-45) ports



10


Ethernet LAN data rates



10, 100, 1000


USB 2.0 ports quantity



1


WAN connection



Ethernet (RJ-45)


Power



Power consumption (max)



89 Watt


Power consumption (typical)



19 Watt


Power supply



100 Watt


Product dimensions



Net Weight (Product, kg)



3.61 kg


Security



Security algorithms



IPSEC


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)


Weight & dimensions



Dimensions (WxDxH)



284 x 178 x 27 mm
