Cisco SB MGBLX1 Gigabit Ethernet LX Mini-GBIC MGBLX1

The Cisco MGBLX1 Transceiver MGE Small Form-Factor Pluggable (SFP) or mini Gigabit Interface Converter (mini-GBIC) is an easy-to-install module that provides a simple way to add fiber connectivity to Cisco 100, 200, 300, and 500 Series switches.

The MGBLX1 transceiver is available for single-mode or multimode fiber-optic cabling and can support distances from 100 meters up to 10 kilometers.

Design



Certification



FCC Part 15 Class B, EN55022 Class B (CISPR 22B), VCCI Class B.


Safety



FDA 21 CFR 1040.10 & 1040.11, EN60950, EN (IEC) 60825-1,2


Logistics data



Harmonized System (HS) code



85176990


Quantity per pack



1 pc(s)


Management features



Hot-swap



Yes


Plug and Play



Yes


Network



Cabling technology



1000Base-LX


Maximum data transfer rate



1000 Mbit/s


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



0 - 70 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-40 - 85 �C


Other features



Connector(s)



LC-LC


Dimensions (WxDxH)



13.4 x 55.7 x 8.5 mm


Fiber type



SMF


Full duplex



Yes


Interface



SFP


Transmit power range



-9.5 - -3 dBmW


Package dimensions



Depth (package,cm)



10 cm


Gross Weight (Package, kg)



0.95 kg


Height (package,cm)



1.78 cm


Width (package,cm)



2.5 cm


Performance



Maximum transfer distance



10000 m


Wavelength



1310 nm


Ports & interfaces



Connectivity technology



Wired


Power



Power consumption (typical)



1 Watt


Product dimensions



Net Weight (Product, kg)



0.55 kg


Product Depth



1.34 cm


Product Height



0.85 cm


Product Width



5.57 cm


Technical details



Harmonized System (HS) code



85176990


Vendor information



Brand Name


Cisco SB


Homepage



http://www.cisco.com


Warranty



5 Year(s)
