Cisco WAP551-E-K9-RFB AP Single Radio 450Mbps w PoE WAP551-E-K9-RFB

High-Performance, Easy-to-Deploy, Secure Business-Class Wireless-N Connectivity
Highlights
- Provides cost-effective selectable or concurrent dual-radio Wireless-N connectivity for high capacity and additional users.
- Gigabit Ethernet LAN interfaces with PoE enable flexible installation.
- SmartSignal Antenna technology optimizes wireless coverage and reception.
- Captive portal enables highly secure guest access with customized roles and rights.
- Single Point Setup requires no controller, for easy cost-effective deployment of multiple access points.
- Works right out of the box with easy installation and simple web-based configuration and wizard.

In today's dynamic business environment, employees are becoming more mobile and collaborative than ever. To stay productive, they need dependable, business-class access to network applications throughout the office. The Cisco Small Business 500 Series Wireless Access Points provide a simple, cost-effective way to extend secure, high-performance mobile networking to your employees and guests, so they can stay connected anywhere in the office. This flexible solution lets you connect dozens of employees, and can scale to accommodate additional users and changing business needs.
The Cisco 500 Series access points use selectable or concurrent dual-band radios for improved coverage and user capacity. Gigabit Ethernet LAN interfaces with Power over Ethernet (PoE) support flexible installation and reduce cabling and wiring costs. Intelligent quality-of-service (QoS) features let you prioritize bandwidth-sensitive traffic for voice over IP (VoIP) and video applications. SmartSignal Antenna technology enables you to extend the reach of your wireless network by optimizing coverage, reception, and performance.
To provide secure guest access to visitors and other users, the Cisco 500 Series access points support a captive portal with multiple authentication options and the ability to configure rights, roles, and bandwidth. A customized guest login page lets you present a welcome message and access details, and reinforces your brand with company logos.
The Cisco 500 Series access points are easy to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. An attractive design with flexible mounting options enables the access points to smoothly blend into any small business environment.
To enhance reliability and safeguard sensitive business information, the Cisco 500 Series access points support both Wi-Fi Protected Access (WPA) Personal and Enterprise, encoding all your wireless transmissions with powerful encryption. In addition, 802.1X RADIUS authentication helps keep unauthorized users out.
Designed to scale smoothly as your organization grows, the access points feature controllerless Single Point Setup that simplifies the deployment of multiple access points without additional hardware. With the Cisco 500 Series access points, you can extend business-class wireless networking to employees and guests anywhere in the office, with the flexibility to meet new business needs for years to come.

Antenna



Antenna features



Integrated antenna


Antenna gain level (max)



5 dBi


Antennas quantity



5


Design



Cable lock slot



Yes


Certification



UL, CAN/CSA, IEC, EN, FCC, RSS, AS/NZS, ICES


Internal



No


LED indicators



LAN, Power, WLAN


Reset button



Yes


Features



2.4 GHz



Yes


5 GHz



Yes


Ethernet LAN data rates



10, 100, 1000


Frequency band



2.4, 5 GHz


Maximum data transfer rate



1000 Mbit/s


Modulation



OFDM


Networking standards



IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u


Number of users



64 user(s)


Quality of Service (QoS) support



Yes


VLAN support



Yes


Wi-Fi data rate (max)



450 Mbit/s


Management features



Firmware upgradeable



Yes


Switch type



Managed


Web-based management



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 85 %


Operating temperature (T-T)



0 - 40 °C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-20 - 70 °C


Package dimensions



Gross Weight (Package, kg)



1.01 kg


Packaging content



AC adapter included



No


Cables included



LAN (RJ-45)


Packaging data



AC adapter included



No


Cables included



LAN (RJ-45)


Performance



Compatible operating systems



Linux OS


Flash memory



32 MB


Internal memory



64 MB


Ports & interfaces



DC-in jack



Yes


Ethernet LAN (RJ-45) ports



1


Power



Power consumption (typical)



7.872 Watt


Power over Ethernet (PoE)



Yes


Product dimensions



Net Weight (Product, kg)



1 kg


Product Depth



23 cm


Product Height



2.5 cm


Product Width



23 cm


Protocols



DHCP client



Yes


Management protocols



SNMP v3, Bonjour


Media access protocol



HTTP, HTTPS


Supported network protocols



IPv4, IPv6, NTP, TCP/IP


Security



Security algorithms



802.1x RADIUS, SSID, WDS, WPA, WPA2, WPS


Vendor information



Brand Name


Cisco


Warranty



1 Year(s)
