Club3D CSV-1596 Usb Gen1 Type-C. 6-In-1 Hub CSV-1596

The Club 3D CSV-1596 is a USB Gen1 Type-C, 6-in-1 Hub with HDMI�8K30Hz-4K120Hz, 2xUSB Type-A, RJ45 and 2xUSB Type-C, Data and PD charging 100 watt, providing an ideal solution for extending the port of Type-C/Thunderbolt host (PC/Laptop/Mobile phone,etc.), especially for those host with a single Type-C port. This hub adopts the latest DP1.4 Alt mode supported IC, enabling to output HDMI� video with max. 8K30Hz-4K120Hz and at the meanwhile transfer USB 3.1 data with max 5Gbps. The USB Type-A and Type-C data ports allow you to connect 4 USB devices simultaneously. 1 Gigabit Ethernet for super fast Ethernet. Besides, the Type-C female supports PD 3.0 PD Charging 100W (15W is dedicated to the functioning of this product, the rest power(max 85W) will be passed to charge for the host. This 6-in-1 Hub will work on all DP Alt mode supported Type-C hosts.

Logistics data



Harmonized System (HS) code



84719000


Network



Ethernet LAN (RJ-45) ports



1


Ethernet LAN data rates



100, 1000


Other features



Cable length



0.3 m


Cable type



Round cable


Package dimensions



Depth (package,cm)



3.5 cm


Gross Weight (Package, kg)



2.47 kg


Height (package,cm)



32 cm


Width (package,cm)



7 cm


Packaging data



Quantity per pack



1 pc(s)


Performance



Certification



ROHS, FCC, CE EMI


HD type



8K Ultra HD


High Dynamic Range (HDR) supported



Yes


Hub interfaces



HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C


Maximum refresh rate



120 Hz


Number of displays supported



1


Plug and Play



Yes


Product colour



Black


Ports & interfaces



HDCP



Yes


HDCP version



1.4/2.3


HDMI ports quantity



1


Host interface



USB 3.2 Gen 1 (3.1 Gen 1) Type-C


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



2


USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity



2


USB Power Delivery



Yes


USB Power Delivery revision



3.0


USB Power Delivery up to



100 Watt


USB Type-C DisplayPort Alternate Mode



Yes


Power



Output current



1.5 A


Output voltage



5 V


Power consumption (max)



7.5 Watt


Product dimensions



Net Weight (Product, kg)



1.9 kg


Product Depth



3.2 cm


Product Height



3.5 cm


Product Width



12.6 cm


Software



Mac operating systems supported



Y, Yes


Windows operating systems supported



Yes


Vendor information



Brand Name


Club3D


Warranty



1 Year(s)
