Club3D CSV-7220 Mst Hub DisplayportT 1.4 To CSV-7220

The CSV-7220 is a MST hub DisplayPort™ 1.4 to DisplayPort™ + HDMI™ 4K60Hz M/F. This DisplayPort™ 1.4 MST hub is designed to cater for your most versatile connectivity demands, such as Tablet, laptop, etc. with a free DP™ (DisplayPort) port.
Give your device more displays. PCs and notebooks are increasingly becoming more powerful and smaller in the physical form factor. With a single DP™1.4 port available you can now drive one-Displayport™ screen simultaneously with a HDMI™ screen at 4K60Hz or One DP™ display at 8K30Hz in MST mode Windows). All it needs is a free DP™ 1.4 port on your Laptop or PC to connect to the MST hub and will provide you with unparalleled connection options for Dual 4K60Hz displays. The setup is easy and simple to do, provided your system supports DP1.4 specifications and DSC1.2 Compression, resolutions can be limited if the source device is lower. The CSV-7220 is externally powered by a USB Type-A to Micro USB cable which comes with the product.

Features



3D



Yes


Cable length



1 m


Cable type



Round cable


Certification



ROHS, FCC, CE EMI


Connector 1



DisplayPort


Connector 1 form factor



Straight


Connector 1 gender



Male


Connector 2



HDMI + DisplayPort


Connector 2 form factor



Straight


Connector 2 gender



Female


DisplayPort version



1.4


HDCP



Yes


HDCP version



1.4/2.2


Mac operating systems supported



Y, Yes


Maximum refresh rate



60 Hz


Maximum resolution



7680 x 4320 Pixels


Plug and Play



Yes


Power source



USB


Product colour



Grey


Refresh rate at maximum resolution



30 Hz


Supported graphics resolutions



3840 x 2160, 5120 x 2880, 7680 x 4320


Supported video modes



2160p, 2880p, 4320p


Windows operating systems supported



Y, Yes


Package dimensions



Depth (package,cm)



3.5 cm


Gross Weight (Package, kg)



0.03 kg


Height (package,cm)



25 cm


Width (package,cm)



7.5 cm


Packaging data



Quantity per pack



1 pc(s)


Product dimensions



Net Weight (Product, kg)



0.02 kg


Product Depth



4.4 cm


Product Height



1.52 cm


Product Width



6.2 cm


Vendor information



Brand Name


Club3D


Warranty



1 Year(s)
