Cyberpower Smart App 1000Va Line Interactive 1U Rackmountable Ups 600W Lcd Disp OR1000ERM1U

CyberPower OR1000ERM1U Line-Interactive UPS offers Simulated Sine Wave output power for office system devices including PCs, workstations, networking devices, and peripherals. It’s typically integrated in the back office and server room environment to ensure a reliable backup power supply during power failures. The UPS has a multifunction LCD display which offers real-time information, including input and output voltage levels, load and battery levels, battery runtime, overload warning, and a silent mode. With the network ports on the UPS, it prevents network devices from being subjected to sudden power surges caused by lightning, thereby avoiding potential system damage. As for battery maintenance, the UPS allows battery hot-swapping, which enables users to perform normal battery maintenance without significant interruption.

Line-interactive UPS Topology
Simulated Sine Wave Output
Overload Protection
Surge and Spike Protection
Phone/Fax/Modem/DSL/Network Protection
USB Connectivity Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Hot-swappable Batteries
EMI and RFI Filtration
LCD Status Display
PowerPanel Management Software

DescriptionSpecification

Type: Rackmountable UPS
Maximum Capacity: 1000VA / 600W
Battery Type: Sealed Lead-acid

Typical Protection: "Surge Suppression: 810
EMI/RFI Filtration
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out"
Inversion: Simulated Sine Wave

Transfer Time: 4 ms
Battery Protection: "Automatic Voltage Regulation (AVR): Single Boost
Overload Protection: Internal Current Limiting, Circuit Breaker"
Input Voltage: Nominal Input Voltage: 230 Vac
Input Voltage Range: 165
271 Vac
Output Voltage: 230 ± 10% Vac
Recharge Time: 8 Hours
Runtime: at Half Load: 14 minutes
at Full Load : 3.5 minutes

Interfaces: "6 x IEC C13
1 x HID Compliant USB Port
1 x Serial Port
RJ11/RJ45 (Combo): 1-in, 1-out"
Visual Indicators: "LCD Panel:
Operation Type, Power Status, Battery Status, Load Status, Other Information

LCD Setting & Control:
Mode Setting, Alarm Setting, Input & Output

LED Indicators:
Power On
"
Audible Indicators: "Battery Mode, Low Battery, Overload, UPS Fault"
Environment: "Operating Temperature: 32
104°F
Operating Temperature: 0
40 °C
Operating Relative Humidity (Non-condensing): 0
95 %
Operating Elevation: 0-9,843 feet (0-3,000 meters)
Storage Temperature: 5
113 °F
Storage Temperature: -15
45 °C
Storage Relative Humidity (Non-condensing): 0
95%
Storage Elevation: 0-49,213 feet (0-15,000 meters)
Online Thermal Dissipation: 24 BTU/hr"
Dimensions: (WxHxD) 433 x 44 x 389 mm
Weight: 13.7 kg
Additional Featues: See Overview / Videos
Accessories: Rackmount Ears
Power Cord
USB Cable
Users Manual
Package Type: Retail
Package Weight: 13.7000 kg
Warranty: 2 Years
