D-Link DGS-1100-24V2/E 24-Port PoE Gigabit Smart DGS-1100-24V2/E

24-Port Gigabit Smart Managed Switch
- 24-Port 100BaseTX Auto-Negotiating 10/100/1000Mbps Switch
- Fanless
- 802.1Q VLAN
- 802.1p QoS
- IGMP snooping
- Loopback detection
- Port mirroring
- Bandwidth control
- Storm control
- 802.3, 802.3u, 802.3x
- SmartConsole Utility
- Web based management
- Cable diagnostics
- Dual Images
- Link Aggregation
- SNMP
- TLS1.1/1.2
- 11" Rackmount Installation

Data transmission



Forwarding rate



35.71 Mpps


Jumbo frames



9216


Jumbo frames support



Yes


MAC address table



8000 entries


Packet buffer memory



4.1 MB


Switching capacity



48 Gbit/s


Design



Certification



FCC, CE, VCCI, C-Tick, BSMI, CCC


Form factor



1U


LED indicators



Y, Yes


Product colour



Black, Grey


Rack mounting



Yes


Management features



Quality of Service (QoS) support



Yes


Switch layer



L2


Switch type



Managed


Web-based management



Yes


Network



10G support



No


Auto MDI/MDI-X



Yes


Auto-negotiation



Yes


Broadcast storm control



Yes


Ethernet LAN data rates



10, 100, 1000


Flow control support



Yes


Full duplex



Yes


Half duplex



Yes


Head-of-line (HOL) blocking



Yes


Link aggregation



Yes


Networking standards



IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x


Number of VLANs



128


Port mirroring



Yes


Rate limiting



Yes


Spanning tree protocol



Yes


Virtual LAN features



Port-based VLAN


VLAN support



Yes


Operational conditions



Heat dissipation



54.3 BTU/h


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



-5 - 50 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-40 - 70 �C


Package dimensions



Depth (package,cm)



35.800000000000004 cm


Gross Weight (Package, kg)



2.39 kg


Height (package,cm)



10.200000000000001 cm


Width (package,cm)



32.9 cm


Performance



Flash memory



16 MB


Mean time between failures (MTBF)



424762 Hour


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Power



AC input frequency



50/60 Hz


AC input voltage



100 - 240 V


Number of power supply units



1


Power consumption (max)



15.9 Watt


Power source



AC


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



1.659 kg


Product Depth



18 cm


Product Height



4.4 cm


Product Width



28 cm


Security



IGMP snooping



Yes


Loop protection



Yes


Sustainability



Sustainability certificates



BSMI, CB, CCC, cUL


Sustainability compliance



Yes


Vendor information



Brand Name


D-Link
