D-Link DGS-1510-20/E 20-Port Gigabit Stackable DGS-1510-20/E

20-Port Gigabit Stackable SmartPro Switch including 2 SFP ports and 2 x 10G SFP+ ports
- 16 x 10/100/1000Mbps Auto-Negotiating Ports
- 2 x Mini-GBIC SFP ports
- 2 x SFP+ ports
- Physical Stacking up to 6 units per stack. Stacking Bandwidth of 40Gb. Topology Linear or Ring.
- D-Link Green 3.0, 802.3az
- Virtual stacking
- Static route
- IPv6 Management/Ready Logo
- Half-/Full-Duplex, auto-negotiation, Auto MDI/MDIX
- IEEE 802.3x Flow Control
- 802.3ad Link Aggregation
- Asymmetric VLAN, Auto Voice VLAN, GVRP
- 802.1p priority queues
- MAC/IP filtering
- MAC/IP-based ACL
- 802.1X port-base Access Control, Port Security, traffic segmentation
- D-Link Safequare Engine
- Smart Console Utility, web based management, compact CLI
- D-View 6.0 support
- 19" Rackmount Installation

Data transmission



Forwarding rate



56.54 Mpps


MAC address table



16384 entries


Packet buffer memory



1.5 MB


Switching capacity



76 Gbit/s


Design



DIN rail mounting



Yes


Form factor



1U


LED indicators



Y, Yes


Number of fans



1 fan(s)


Product colour



Grey


Rack mounting



Yes


Reset button



Yes


Stackable



Yes


Management features



MIB support



Y


Switch layer



L2/L3


Switch type



Managed


Network



10G support



Yes


Auto MDI/MDI-X



Yes


Full duplex



Yes


MAC address auto-aging supported



Yes


MAC address auto-learning supported



Yes


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x


VLAN support



Yes


Operational conditions



Heat dissipation



41.602 BTU/h


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



-5 - 50 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



0 - 95 �C


Package dimensions



Depth (package,cm)



34.6 cm


Gross Weight (Package, kg)



2.71 kg


Height (package,cm)



10.4 cm


Width (package,cm)



34.6 cm


Performance



Noise level



43.8 dB


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



16


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Installed SFP modules quantity



2


Installed SFP+ modules quantity



2


SFP module slots quantity



2


SFP+ module slots quantity



2


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Power source



AC


Power supply included



Yes


Product dimensions



Net Weight (Product, kg)



1.901 kg


Product Depth



18 cm


Product Height



4.4 cm


Product Width



28 cm


Security



Access Control List (ACL)



Yes


DHCP features



DHCP snooping


Vendor information



Brand Name


D-Link
