D-Link DMC-G01LC/E 10/100/1000Mbps to SFP Standal DMC-G01LC/E

D-Link�s DMC-G01LC standalone media Converter turns a copper Ethernet link into a fiber link, allowing for an ultra-fast, long distance connection. Installation of a standalone media converter is simple, and allows you to tap into fiber speeds with ease. Instead of requiring an investment in an entire chassis, a standalone media converter provides the same high-quality conversion on a unit-by-unit basis. You can save space and cut costs while still extending your network over long distances of 10 km and beyond on a fiber optic line.

SFP Optical Transceivers for Maximum Flexibility
The fiber side of the DMC-G01LC utilizes a 100/1000 SFP port for maximum flexibility. Using the appropriate SFP transceiver (purchased separately) it can support either multimode or single-mode fiber, varying wavelengths, and speeds of either 100 Mbps or 1000 Mbps.

10/100/1000 Copper Speeds
The copper side of the DMC-G01LC auto-negotiates to 10Mbps, 100Mbps or 1000Mbps, ensuring the connection functions at the highest possible speed while remaining compatible with the link partner. It supports auto MDI/MDIX, half/full duplex operation at 10/100 Mbps and full duplex operation at 1000 Mbps.

Plug & Play
The DMC-G01LC supports standard technologies that makes it easy to operate, like 802.3u. 802.3x and 802.3ab. There�s no management software to configure � simply connect the power, connect the cables, and start converting.

Design



Certification



CE, FCC, VCCI, BSMI


Internal



No


LED indicators



Y, Yes


Product colour



Grey


Safety



LVD, UL/cUL


Logistics data



Master (outer) cases per pallet (air)



40 pc(s)


Master (outer) cases per pallet (sea)



64 pc(s)


Pallet gross length



110 cm


Pallet gross weight (air)



341.1 kg


Pallet gross weight (sea)



534.56 kg


Pallet gross width



120 cm


Pallet height (air)



131 cm


Pallet height (sea)



202.3 cm


Products per pallet (air)



800 pc(s)


Products per pallet (sea)



1280 pc(s)


Products per shipping (inner) case



20 pc(s)


Shipping (inner) case gross weight



8.04 kg


Shipping (inner) case gross weight



8.04 kg


Shipping (inner) case height



23.6 cm


Shipping (inner) case length



50.4 cm


Shipping (inner) case net weight



7.16 kg


Shipping (inner) case width



29.4 cm


Network



Auto MDI/MDI-X



Yes


Ethernet interface type



Gigabit Ethernet


Ethernet LAN data rates



10, 100, 1000


Maximum data transfer rate



1000 Mbit/s


Networking standards



IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 50 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-10 - 70 �C


Package dimensions



Depth (package,cm)



14 cm


Gross Weight (Package, kg)



0.52 kg


Height (package,cm)



9.7 cm


Width (package,cm)



10.5 cm


Performance



Mean time between failures (MTBF)



506711 Hour


Ports & interfaces



Connectivity technology



Wired


DC-in jack



Yes


Ethernet LAN (RJ-45) ports



1


Fiber optic connector



SFP


Fiber ports quantity



1


Power



Input voltage



230 - 240 V


Output current



1 A


Output voltage



5 V


Product dimensions



Net Weight (Product, kg)



0.3212 kg


Product Depth



9.5 cm


Product Height



2.5 cm


Product Width



7 cm


Technical details



Harmonized System (HS) code



85176990


Master (outer) cases per pallet (air)



40 pc(s)


Master (outer) cases per pallet (sea)



64 pc(s)


Pallet gross length



110 cm


Pallet gross weight (air)



341.1 kg


Pallet gross weight (sea)



534.56 kg


Pallet gross width



120 cm


Pallet height (air)



131 cm


Pallet height (sea)



202.3 cm


Products per pallet (air)



800 pc(s)


Products per pallet (sea)



1280 pc(s)


Products per shipping (inner) case



20 pc(s)


Shipping (inner) case gross weight



8.04 kg


Shipping (inner) case height



23.6 cm


Shipping (inner) case length



50.4 cm


Shipping (inner) case net weight



7.16 kg


Shipping (inner) case width



29.4 cm


Vendor information



Brand Name


D-Link


Warranty



2 Year(s)
