D-Link DUB-E130 USB-C to Gigabit Ethernet DUB-E130

GIGABIT ETHERNET CONNECTIVITY

The DUB-E130 USB-C to Gigabit Ethernet Adapter plugs into any available USB Type-C port on your computer to enable you to connect to an Ethernet network at speeds up to 1Gbps which is up to ten times faster transfer speeds compared to previous standards. HIgh-speed Gigabit Ethernet allows you to transfer large files in no time, or make light work of backups to a server or network storage device.

EASY TO INSTALL AND USE

The DUB-E130 USB-C to Gigabit Ethernet Adaper connects to your computer's USB Type-C port and is ready to run as soon as it's plugged in. Plug-and-Play design ensures that there is no need to change any configuration settings or install any software on your computer.

ERERGY-SAVING FUNCTIONAILITY

Power to the DUB-E130 is provided directly by the USB Type-C port, eliminating the need for an external AC power adapter. The DUB-E130 not only supports the USB3.0 standard's power-saving features, but also incldues an energy-saving suspend and resume function to minimize power consumption when network traffic is light, the device is idle, or when the Ethernet cable is unplugged. This feature is especially useful in helping to conserve battery life, allowing you to keep working for longer without needing to recharge.

Design



Certification



CE, FCC


Internal



No


LED indicators



Link, Speed


Plug and Play



Yes


Product colour



White


Logistics data



Master (outer) cases per pallet (air)



27 pc(s)


Master (outer) cases per pallet (sea)



51 pc(s)


Pallet gross length



120 cm


Pallet gross weight (air)



166.77 kg


Pallet gross weight (sea)



298.77 kg


Pallet gross width



110 cm


Pallet height (air)



120 cm


Pallet height (sea)



192 cm


Products per pallet (air)



1080 pc(s)


Products per pallet (sea)



2040 pc(s)


Products per shipping (inner) case



40 pc(s)


Shipping (inner) case gross weight



5.5 kg


Shipping (inner) case gross weight



5.5 kg


Shipping (inner) case height



30.2 cm


Shipping (inner) case length



33.5 cm


Shipping (inner) case net weight



1.4 kg


Shipping (inner) case width



28.6 cm


Network



Ethernet interface type



Gigabit Ethernet


Ethernet LAN



Yes


Ethernet LAN data rates



10, 100, 1000


Full duplex



Yes


Maximum data transfer rate



1000 Mbit/s


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3u


Wake-on-LAN ready



Yes


Operational conditions



Operating relative humidity (H-H)



20 - 80 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-20 - 70 �C


Other features



Harmonized System (HS) code



85176990


Package dimensions



Depth (package,cm)



14.3 cm


Gross Weight (Package, kg)



0.13 kg


Height (package,cm)



3.3 cm


Width (package,cm)



14 cm


Ports & interfaces



Connectivity technology



Wired


Ethernet LAN (RJ-45) ports



1


Host interface



USB Type-C


Interface



Ethernet


USB version



2.0/3.2 Gen 2 (3.1 Gen 2)


Power



Input current



0.5 A


Output voltage



5 V


Power consumption



176 mA


USB powered



Yes


Product dimensions



Net Weight (Product, kg)



0.0155 kg


Product Depth



20.5 cm


Product Height



1.5 cm


Product Width



2.65 cm


System requirements



Mac operating systems supported



Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks


Windows operating systems supported



Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP


Vendor information



Brand Name


D-Link


Warranty



2 Year(s)
