D-Link GO-SW-8E/E 8-Port 10/100M Desktop Switch GO-SW-8E/E

The dlinkgo GO-SW-8E 8-Port Fast Ethernet Easy Desktop Switch allows you to quickly set up a fast, reliable, and efficient wired network in your home or office. The GO-SW-8E is an unmanaged 10/100Mbps switch designed to enhance small workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands. Connect the GO-SW-8E to multiple computers to share files and folders, or connect it to a router to share an Internet connection.

Effortless High Speed Networking.

The GO-SW-8E features easy access auto sensing 10/100 Mbps Ethernet ports with a LED indicator for each port to quickly distinguish link status and activity. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, to get you the maximum speed possible for each device connected to your network, for faster browsing, video streaming, and online gaming. The GO-SW-8E also supports Auto MDI/MDIX Crossover, allowing you to connect each port directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.

Reliable Plug and Play Installation.

The GO-SW-8E is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, so right away you�re easily able to connect multiple computers, share files, music, and video across your home or small office network, or even create a multi-player gaming environment. 802.3x flow control on each port minimizes dropped packets when the port�s receiving buffer is full. This gives you a more reliable connection for all of your connected devices.

Environmentally Friendly.

The GO-SW-8E features D-Link Green technology, which drastically reduces energy consumption. If there is no computer connected to a port or a connected computer is powered off, the port will automatically enter �sleep mode�, greatly reducing the power used for that port without interrupting the network connection. In addition, the switch automatically detects the length of connected Ethernet cables and adjusts their power usage accordingly without affecting performance. This considerably lowers overall energy usage, which both saves you money and helps the environment, without the need for micro-management.

Compact and Silent.

The GO-SW-8E has a sleek and compact design, so that you can place it in any easily accessible location and have it stay out of your way. The power connector and ports are all located at the rear of the switch allowing you to tuck the cables away conveniently. The GO-SW-8E does not use a fan, so the switch operates silently but effectively, letting you watch movies streamed off the Internet without distraction, or browse the web in peace.

Data transmission



Jumbo frames support



Yes


MAC address table



2000 entries


Store-and-forward



Yes


Design



LED indicators



Y, Yes


Product colour



White


Rack mounting



No


Stackable



No


Logistics data



Harmonized System (HS) code



85176990


Management features



Switch type



Unmanaged


Network



10G support



No


Auto MDI/MDI-X



Yes


Full duplex



Yes


Networking standards



IEEE 802.3, IEEE 802.3az, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-10 - 70 �C


Other features



Power LED



Yes


Package dimensions



Depth (package,cm)



16.4 cm


Gross Weight (Package, kg)



0.287 kg


Height (package,cm)



9.8 cm


Width (package,cm)



10.5 cm


Performance



Harmonized System (HS) code



85176990


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



8


Basic switching RJ-45 Ethernet ports type



Fast Ethernet (10/100)


Power connector



DC-in jack


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



0.075 kg


Product Depth



7.85 cm


Product Height



2.38 cm


Product Width



14.15 cm


Technical details



Master (outer) cases per pallet (air)



50 pc(s)


Master (outer) cases per pallet (sea)



50 pc(s)


Pallet gross length



110 cm


Pallet gross weight (air)



333.73 kg


Pallet gross weight (sea)



333.73 kg


Pallet gross width



120 cm


Pallet height (air)



188.5 cm


Pallet height (sea)



188.5 cm


Products per pallet (air)



1000 pc(s)


Products per pallet (sea)



1000 pc(s)


Products per shipping (inner) case



20 pc(s)


Shipping (inner) case gross weight



6.2806 kg


Shipping (inner) case gross weight



6.2806 kg


Shipping (inner) case height



35 cm


Shipping (inner) case length



54.3 cm


Shipping (inner) case net weight



3.8228 kg


Shipping (inner) case width



21.1 cm


Vendor information



Brand Name


D-Link


Warranty



2 Year(s)
