Delock DELOCK-87772 87772 Notebook Dock/Port DELOCK-87772

This docking station by Delock can be connected to a computer with a USB-C™ DP Alt Mode or Thunderbolt™ 3 port and provides a variety of interfaces. Up to three monitors can be operated simultaneously at the DisplayPort and HDMI outputs. Four built-in USB ports allow the use of peripherals, connections for headset and Gigabit network, as well as SD and Micro SD slot complete the features.

Multi-Stream Transport (MST)
The product is an MST hub and supports the extended desktop configuration of DisplayPort. This allows multiple monitors to be combined into one large display. The maximum resolution for simultaneous playback on two or three monitors depends on the system and connected hardware.

USB Power Delivery (USB PD 3.0) support up to 85 watt
The docking station has a USB Type-C™ Power Delivery port to connect the power supply of the laptop or tablet to charge it.

Stand
The Delock docking station can be operated either horizontally or vertically. A stand is included for vertical operation.

Logistics data



Harmonized System (HS) code



84733020


Network



Ethernet LAN



Yes


Ethernet LAN (RJ-45) ports



1


Ethernet LAN data rates



10, 100


Package dimensions



Gross Weight (Package, kg)



2.47 kg


Packaging content



AC adapter included



Yes


Cables included



USB Type-C to USB Type-C


User guide



Yes


Packaging data



Quantity per pack



1 pc(s)


Performance



Card reader integrated



Yes


Compatible memory cards



MicroSD (TransFlash), SD


Product colour



Grey


Ports & interfaces



Connectivity technology



Wired


DC-in jack



Yes


DisplayPorts quantity



2


HDMI ports quantity



1


Headphone connectivity



3.5 mm


Headphone outputs



1


Host interface



Thunderbolt 3


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



3


USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity



2


Power



AC input frequency



50 - 60 Hz


AC input voltage



100-240 V


Input current



0.8 A


Output current



2 A


Output voltage



12 V


Power source type



AC


Product dimensions



Net Weight (Product, kg)



1.9 kg


Product Depth



78 cm


Product Height



1.8 cm


Product Width



7.7 cm


Software



Mac operating systems supported



Y, Yes


Mobile operating systems supported



Android 9.0


Windows operating systems supported



Windows 10, Windows 8.1


Vendor information



Brand Name


Delock


Warranty



1 Year(s)
