Edimax GS-1008PL V2 GS-1008PL V2 network switch GS-1008PL V2

PoE Long Range Extension

?Break Through 100 Meters PoE Distance Limitation

Supports PoE power output over a distance up to 200 meters overcoming the 100 meters limit on Ethernet UTP cable with the PoE Extend �ON�, the GS-1008PL V2 provides an additional solution for 802.3at/af PoE distance extension, thus saving the cost of Ethernet cable installation.

Innovative Port-based VLAN

Port Isolated from Affecting Each Other

The GS-1008PL V2 features port-based VLAN where ports can be easily isolated from each other. This can help to prevent IP camera�s multicast or broadcast storms from affecting each other.

Easy Hardware QoS

Video & Voice Traffic Priority

Supports 802.1p QoS via DIP switch port 4. This ensures first priority for video and voice traffic for reduced package loss, lower latency and jitter on the network.

Safe Power Backfeed Protection

Avoid Damaging the PoE Ports

Each port equipped with power backfeed protection to avoid damaging the PoE ports while the non-standard PSE (Power Sourcing Equipments) are connected.
Edimax GS-1000PL V2 Long Range 8-Port Gigabit Ethernet PoE+ Switch with DIP Switch, PoE power backfeed protection

Data transmission



Forwarding rate



1.488 Mpps


Jumbo frames



9216


Jumbo frames support



Yes


MAC address table



4096 entries


Store-and-forward



Yes


Switching capacity



16 Gbit/s


Design



Certification



CE, FCC, LVD


Form factor



1U


Housing material



Metal


LED indicators



Activity, Link, Power


Product colour



Black


Rack mounting



Yes


Management features



Quality of Service (QoS) support



Yes


Switch layer



L2


Switch type



Managed


Multicast features



Multicast support



Yes


Network



10G support



No


Broadcast storm control



Yes


Ethernet LAN data rates



10, 100, 1000


Full duplex



Yes


Half duplex



Yes


Networking standards



IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x


VLAN support



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-40 - 70 �C


Package dimensions



Depth (package,cm)



27.5 cm


Gross Weight (Package, kg)



2 kg


Height (package,cm)



7.3 cm


Width (package,cm)



31.8 cm


Performance



Fanless



Yes


Harmonized System (HS) code



85176990


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



8


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Gigabit Ethernet (copper) ports quantity



8


Power



Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



Yes


Power over Ethernet (PoE) type supported



Active PoE


Power over Ethernet plus (PoE+) ports quantity



8


Total Power over Ethernet (PoE) budget



70 Watt


Product dimensions



Net Weight (Product, kg)



1.609 kg


Product Depth



18.4 cm


Product Height



4.4 cm


Product Width



26.5 cm


Technical details



Sustainability certificates



CE


Sustainability compliance



Yes


Vendor information



Brand Name


Edimax


Warranty



1 Year(s)
