Elo Touch Solutions E239980 Power Converter Kit E239980

The 24 VDC Converter Kit provides conversion from 24V to 12V, which allows kiosk manufacturers to leverage a common 24V power supply in their kiosk design and have a single AC connection. On the 1598L open frame touchscreen there are mounting features that enable the converter to be mounted on the back of the monitor. The power converter can also be used with other Elo 90-Series open frames via other kiosk mounting options.

Package dimensions (verified)



Depth Verified



11.7 cm


Gross Weight Verified



0.224 kg


Height Verified



8.7 cm


Width Verified



15.7 cm


Power



DC input voltage



24 V


Input current



1.9 A


Output current



3500 mA


Output voltage



12 V


Product dimensions



Net Weight (Product, kg)



0.124 kg


Product Depth



5.71 cm


Product Height



2.04 cm


Product Width



9.07 cm


Technical details



Operating relative humidity (H-H)



20 - 80 %


Operating temperature (T-T)



0 - 50 �C


Product colour



Black


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-20 - 70 �C


Vendor information



Brand Name


Elo Touch Solutions


Homepage



https://www.elotouch.com/wallaby-self-service-stands.html


Warranty



3 Year(s)
