Enermax ERT1050EWT Revolution Dfx Power Supply ERT1050EWT

INTEL ATX 3.0 & PCIe 5.0 READY!
The REVOLUTION D.F. X series meets the Intel ATX 3.0 specification with a native PCIe 5.0 600W 12VHPWR cable providing stable and reliable power to your next generation graphics cards including NVIDIA� GeForce RTX� 40 Series.

THE MOST ADVANCED PERFORMANCE
The REVOLUTION D.F. X meets all the Intel ATX 3.0 standard including up to 200% power excursion which ensures consistent and reliable power delivery to your graphics cards during intensive gaming or overclocking sessions, and 70% efficiency in 2% loading as well as less than 200ms power-on time.

POWER UP WITH 600W 12VHPWR CABLE
With the arrival of PCIe 5.0, the native 600mm 12VHPWR cable can deliver up to 600W of power from the 12VHPWR connector to the latest graphics cards and avoid overloading with single rail +12V design.

EXTRA CABLE FOR MULTIPLE USAGE
The REVOLUTION D.F. X helps you get ready for the future with another 600mm adaptor cable with dual 8-pin PCIe connectors for PSU side and 12VHPWR connector for GPU side, it allows you to build with flexibility.

HOW TO PROPERLY PLUG THE 12+4 PIN 12VHPWR CABLE TO PREVENT DAMAGE
Use your fingers to hold both sides of the cable and insert the cable into the port straight in line with the port. Make sure to insert the cable firmly and evenly straight in without any gaps or bending under 40mm from the plug downwards.

LIGHT IT UP WITH ARGB SIDE PANEL
To stand out from all the ATX 3.0 power supplies, the REVOLUTION D.F. X comes with a ARGB side panel with built-in 14 lighting modes. It supports synchronization with supported motherboard�s software.

RGB ON/OFF WITH RGB CONTROL BUTTON
The RGB control button next to the power switch allows you to turn it off at night with one push. You can also switch directly between the built-in 14 lighting modes via the RGB control button.

UST-FREE ROTATION TECHNOLOGY ENSURES A STABLE POWER DELIVERY
With ENERMAX�s patented Dust-free Rotation technology, which is an innovative self-cleaning solution that enable the fan to blow away dust upon powering on, it ensures the REVOLUTION D.F. X remains cleanness, prevent any future disruption and ensure a stable power delivery for years.

SUPERIOR EFFICIENCY EXTEND YOUR PC�S LIFESPAN
As the efficiency becomes more and more crucial for the environment, the REVOLUTION D.F. X is 80 PLUS� Gold certified with efficiency over 90% on standard loading, which reduce unnecessary power consumption during operation and effectively save energy.

COMPACT 140MM FOR FRIENDLY INSTALLATION
REVOLUTION D.F. X is one of the smallest high wattage power supplies with a compact 140mm-depth size, providing more options for friendly installation in 99% of mainstream cases.

ENERMAX UNIQUE AIR GUARD FOR BETTER AIRFLOW
The ENERMAX air guard will benefit the cooling performance while decreasing the fan noise with the wider space of air outlet.

Design



Cooling type



Active


Fan diameter



12 cm


Product colour



Black


Operational conditions



Operating relative humidity (H-H)



20 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-20 - 70 �C


Package dimensions



Depth (package,cm)



11.5 cm


Gross Weight (Package, kg)



0.65 kg


Height (package,cm)



21 cm


Width (package,cm)



32 cm


Performance



80 PLUS certification



80 PLUS Gold


ATX version



3.0


Bearing technology



FDB


Mean time between failures (MTBF)



100000 Hour


Power supply unit (PSU) form factor



ATX


Purpose



PC


Ports & interfaces



Cabling type



Fully-Modular


CPU power connector (4+4 pin)



Yes


Floppy disk drive cable length



10 cm


Floppy disk drive connector



Yes


Floppy drive power connector



1


Motherboard power cable length



65 cm


Motherboard power connector



20+4 pin ATX


Number of SATA power connectors



12


PCI Express power connectors (6+2 pin)



4


Peripheral (Molex) power cable length



150, 500


Peripheral (Molex) power connectors (4-pin)



6


SATA power cable length



150, 450


Power



AC input frequency



47 - 63 Hz


AC input voltage



100 - 240 V


Combined power (+12V)



1050 Watt


Combined power (+3.3V)



130 Watt


Combined power (+5V)



130 Watt


Combined power (+5Vsb)



15 Watt


Combined power (-12V)



3.6 Watt


Efficiency



92 %


Input current



13-6.5 A


Max output current (+12V)



87.5 A


Max output current (+3.3V)



20 A


Max output current (+5V)



20 A


Max output current (+5Vsb)



3 A


Max output current (-12V)



0.3 A


Power protection features



Over power, Over voltage, Under voltage, Short circuit


Total power



1050 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



14 cm


Product Height



8.6 cm


Product Width



15 cm


Technical details



Sustainability certificates



RoHS, EAC, CE


Sustainability compliance



Yes


Vendor information



Brand Name


Enermax


Warranty



1 Year(s)
