Exsys EX-11099-2 Interface Cards/Adapter EX-11099-2

he EX-11099-2 USB 3.0 PCI-Express card offer you two Super-Speed USB 3.0 ports in a 3.5-inch Front-Bay. The EX-11099 it�s design for connect two more USB 1.1, 2.0 or 3.0 peripheral device to your Workstation, Desktop or Server. He support USB 1.1 Low-Speed (1.5Mbps), Full-Speed (12Mpbs), USB 2.0 High-Speed (480Mbps) and USB 3.0 Super-Speed (5Gbps). It is an ideal technology for external storage devices, digital cameras, webcams, scanners and much more. For support power 900mA to the external USB 3.0 ports, need the additional power from the PC power supply.

3.5-inch Bay for connect more easy the Peripheral device
Compliant with USB 3.0 and Intel xHCI specification
Supports all USB Compliant Data Transfer Type such as Control/Bulk/Interrupt/Isochronous
Support up to 123 device
Fully PCI Express Gen2 Specification Compliant
Support �Hot Swapping� and �Plug-and-Play�
Chip-Set: NEC uPD720202

Design



Internal



Yes


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 55 �C


Storage temperature (T-T)



-20 - 80 �C


Package dimensions



Gross Weight (Package, kg)



0.26 kg


Packaging data



Drivers included



Yes


Manual



Yes


Ports & interfaces



Host interface



Mini PCI Express


Output interface



USB 3.2 Gen 1 (3.1 Gen 1)


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



6.1 cm


Product Width



6.5 cm


System requirements



Linux operating systems supported



Yes


Server operating systems supported



Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Small Business Server 2003, Windows Small Business Server 2008


Windows operating systems supported



Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Exsys


Warranty



1 Year(s)
