Fractal Design FD-C-MES2N-02 Meshify 2 Nano White FD-C-MES2N-02

Robust cooling
- Pre-installed Dynamic X2 GP 1x 120 mm and 1x 140 mm fans ensure smooth airflow with minimal noise
- Install up to 6x 120 mm or 3x 140 mm fans and front radiators up to 280 mm
- Room for GPUs up to 306 mm long including front fans with 331 mm total space

All access
- Fully removable top panel and a top fan bracket that opens to provide excellent interior access and easy cable routing
- Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
- Front filter with double layered detachable nylon for increased airflow

Slick and streamlined
The open interior layout creates a smooth airflow path from intake to rear exhaust

Guided airflow
- Two-part modular air duct for increased GPU airflow
- Bridgeless PCI expansion slots ensure unrestricted GPU exhaust

More in store
- Flexible storage option supporting one 3.5� drive and three 2.5�� drives
- Integrated cable guides with cable straps further simplify cable management behind the board

Bolt-free glass
- Seamlessly integrated TG panel with steel frame support and bolt-free top-latching mechanism
- Front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts

Type-C interface
USB-C front I/O offers quick access to fast charging and speeds up to 10 Gbps

Cooling



Bottom fans diameters supported



120


Front fans diameters supported



120, 140


Front fans installed



1x 140 mm


Front radiator sizes supported



120, 140, 240, 280


Number of bottom fans supported (max)



1


Number of front fans supported (max)



2


Number of rear fans supported (max)



1


Number of top fans supported (max)



2


Rear fans diameters supported



120


Rear fans installed



1x 120 mm


Rear radiator sizes supported



120


Top fans diameters supported



120, 140


Design



Anti-dust filter



Yes


Cable management



Yes


Material



Steel, Tempered glass


Maximum CPU cooler height



16.7 cm


Maximum graphics card length



33.1 cm


Maximum PSU length



20 cm


Number of 2.5" bays



3


Number of 3.5" bays



1


Number of expansion slots



2


On/off button



Yes


Product colour



White


Reset button



Yes


Side window



Yes


Supported motherboard form factors



Mini-DTX, Mini-ITX


Tempered glass panel(s)



Yes


Type



PC


Package dimensions



Depth (package,cm)



41.2 cm


Gross Weight (Package, kg)



7.67 kg


Height (package,cm)



46.2 cm


Width (package,cm)



27.7 cm


Packaging content



Manual



Yes


Ports & interfaces



Audio input



Y


Audio output



Y


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



2


USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity



1


Power supply



Power supply included



No


Supported power supply form factors



ATX


Product dimensions



Net Weight (Product, kg)



5.9 kg


Product Depth



39.6 cm


Product Height



36.1 cm


Product Width



20.5 cm


Storage



SSD form factor



2.5"


Supported HDD sizes



2.5, 3.5


Vendor information



Brand Name


Fractal Design


Warranty



1 Year(s)
