Fsp
FSP PPA450AD01 Hexa 85+ Pro 450W Power PPA450AD01
(No reviews yet)
Write a Review
- UPC:
- 0000000000000
- MPN:
- PPA450AD01
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
HEXA 85+ PRO series is ATX PSU certified with 80 PLUS® Bronze, featured with DC to DC module and +12V single-rail design, taken with full Japanese capacitors and quiet 120mm silent fan, built-in with complete protections: OCP, OVP, SCP, OPP, and approved by the latest global safety regulation 62368 . Besides, the all black-cable design saves your system an optimal airflow space that allows for easy cable management and a polished look. HEXA 85+ PRO series power ranges from 350W, 450W, 550W to 650W to satisfy various needs.
Design
Cooling type
Active
Fan diameter
12 cm
Fan location
Top
Number of fans
1 fan(s)
On/off switch
Yes
Product colour
Black
Logistics data
Harmonized System (HS) code
84733020
Package dimensions
Gross Weight (Package, kg)
0.65 kg
Packaging content
Cables included
CPU, PCIe, Peripheral (Molex), SATA
Performance
80 PLUS certification
80 PLUS Bronze
ATX version
2.5
Bearing technology
Sleeve
EPS version
2.92
Power supply unit (PSU) form factor
ATX
Purpose
PC/Server
Ports & interfaces
ATX Power connector (24-pin)
Yes
Cabling type
Non-Modular
CPU power connector (4+4 pin)
Yes
Floppy disk drive connector
Yes
Floppy drive power connector
1
Motherboard power connector
24-pin ATX
Number of SATA power connectors
5
PCI Express connector
Yes
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
2
Power
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Combined power (-12V)
3.6 Watt
Combined power (+12V)
450 Watt
Combined power (+3.3V)
85 Watt
Combined power (+5V)
85 Watt
Combined power (+5Vsb)
12.5 Watt
Efficiency
85 %
Hold time
17 Millisecond
Input current
6-2.5 A
Max output current (-12V)
0.3 A
Max output current (+12V)
37.5 A
Max output current (+3.3V)
16 A
Max output current (+5V)
16 A
Max output current (+5Vsb)
2.5 A
Power Factor Correction (PFC) type
Active
Power protection features
Over current, Over power, Over voltage, Short circuit
Total power
450 Watt
Product dimensions
Net Weight (Product, kg)
0.5 kg
Product Depth
15 cm
Product Height
8.6 cm
Product Width
14 cm
Vendor information
Brand Name
FSP
Warranty
1 Year(s)
