Grandstream GWN7701P Network Switch Unmanaged GWN7701P

The GWN7700 series are unmanaged network switches that provide a quick and cost-effective way to add high-speed Gigabit connectivity to home offices and small/medium businesses. It requires no configuration or installation, offers a desktop and wall-mountable design, and provides auto MDI/MDIX to eliminate the need for crossover cables. Each port supports auto-negotiation to allow the GWN7700 series to recognize the link speed of any 10/100/1000Mbps network device and intelligently adjust for compatibility and optimal performance. The PoE (Power-over-Ethernet) models provide ports with IEEE 802.3af/at compliant, smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points, and other PoE endpoints. The plug-and-play GWN7700 series are the ideal unmanaged network switches for home offices and small-to-medium businesses.

Data transmission



Jumbo frames



9


Jumbo frames support



Yes


Switching capacity



16 Gbit/s


Design



LED indicators



Activity, Power


Product colour



Black


Management features



Quality of Service (QoS) support



Yes


Switch type



Unmanaged


Multicast features



Multicast support



Yes


Network



10G support



No


Active link detection



Yes


Auto-negotiation



Yes


Ethernet LAN data rates



10, 100, 1000


Networking standards



IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x


Package dimensions



Depth (package,cm)



23 cm


Gross Weight (Package, kg)



1.3 kg


Height (package,cm)



5.1 cm


Width (package,cm)



21 cm


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



8


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Installed SFP+ modules quantity



1


Power



DC input voltage



48 - 53.5 V


Input current



1.22 A


Power consumption (max)



3 Watt


Power source



DC


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



Yes


Power over Ethernet (PoE) ports quantity



4


Product dimensions



Net Weight (Product, kg)



1 kg


Product Depth



19 cm


Product Height



2.8 cm


Product Width



10 cm


Security



IGMP snooping



Yes


Vendor information



Brand Name


Grandstream


Warranty



1 Year(s)
