Hewlett Packard Enterprise 461461-B21-RFB Dual-Core Xeon CPU X5260 461461-B21-RFB

The Dual-Core Intel� Xeon� Processor 5200 Series is a server/workstation processor utilizing two 45-nm Hi-k next generation Intel� Core� microarchitecture cores. The processor is manufactured on Intel�s 45 nanometer process technology combining high performance with the power efficiencies of a low-power microarchitecture. The Dual-Core Intel� Xeon� Processor 5200 Series maintains the tradition of compatibility
with IA-32 software. Some key features include on-die, primary 32-kB instruction cache and 32-kB write-back data cache in each core and 6 MB Level 2 cache with Intel� Advanced Smart Cache architecture. The processors� Data Prefetch Logic speculatively fetches data to the L2 cache before an L1 cache requests occurs, resulting in reduced effective bus latency and improved performance. The 1333 MHz Front Side Bus (FSB) is a quad-pumped bus running off a 333 MHz system clock making 10.66 GBytes per second data transfer rates possible. The 1600 MHz Front Side Bus (FSB) is a quadpumped bus running off a 400 MHz system clock making 12.80 GBytes per second data transfer rates possible.

Enhanced thermal and power management capabilities are implemented including Intel� Thermal Monitor 1, Intel� Thermal Monitor 2 and Enhanced Intel SpeedStep� Technology. These technologies are targeted for dual processor configurations in enterprise environments. Intel� Thermal Monitor 1 and Intel� Thermal Monitor provide efficient and effective cooling in high temperature situations. Enhanced Intel
SpeedStep Technology provides power management capabilities to servers and workstations.

Dual-Core Intel� Xeon� Processor 5200 Series features include Intel� Wide Dynamic Execution, enhanced floating point and multi-media units, Streaming SIMD Extensions 2 (SSE2), Streaming SIMD Extensions 3 (SSE3), and Streaming SIMD Extensions 4.1 (SSE4.1). Advanced Dynamic Execution improves speculative execution and branch prediction internal to the processor. The floating point and multi-media units include
128-bit wide registers and a separate register for data movement. SSE3 instructions provide highly efficient double-precision floating point, SIMD integer, and memory management operations.

The Dual-Core Intel� Xeon� Processor 5200 Series support Intel� 64 Architecture as an enhancement to Intel's IA-32 architecture. This enhancement allows the processor to execute operating systems and applications written to take advantage of the 64-bit extension technology.

In addition, the Dual-Core Intel� Xeon� Processor 5200 Series supports the Execute Disable Bit functionality. When used in conjunction with a supporting operating system, Execute Disable allows memory to be marked as executable or non executable. This feature can prevent some classes of viruses that exploit buffer overrun vulnerabilities and can thus help improve the overall security of the system.

The Dual-Core Intel� Xeon� Processor 5200 Series support Intel� Virtualization Technology for hardware-assisted virtualization within the processor. Intel Virtualization Technology is a set of hardware enhancements that can improve virtualization solutions. Intel Virtualization Technology is used in conjunction with Virtual Machine.

Features



Execute Disable Bit



Yes


Market segment



Server


Number of Processing Die Transistors



410 M


Processing Die size



107 mm�


Thermal Monitoring Technologies



Yes


Graphics



On-board graphics card



No


Operational conditions



Tcase



66 �C


Other features



Intel� Virtualization Technology (Intel� VT)



VT-x


Package dimensions



Gross Weight (Package, kg)



1.1 kg


Power



Thermal Design Power (TDP)



80 Watt


VID Voltage Range



0.850 - 1.3500 V


Processor



Component for



Server/workstation


Processor base frequency



3.33 GHz


Processor cache



6 MB


Processor cache type



L2


Processor cores



2


Processor family



Intel� Xeon� 5000 Sequence


Processor frequency



3.33 GHz


Processor front side bus



1333 MHz


Processor lithography



45 nm


Processor model



X5260


Processor operating modes



64-bit


Processor socket



LGA 771 (Socket J)


Thermal Design Power (TDP)



80 Watt


VID Voltage Range



0.850 - 1.3500 V


Processor special features



Intel Virtualization Technology (VT-x)



Yes


Product dimensions



Net Weight (Product, kg)



1 kg


Vendor information



Brand Name


Hewlett Packard Enterprise


Homepage



http://welcome.hp.com/country/us/en/prodserv/printer-computer-accessories.html


Warranty



1 Year(s)


Weight & dimensions



Processor package size



3.75 cm
