Hewlett Packard Enterprise JG539A-RFB 1910-24-PoE Switch JG539A-RFB

HP 1910 switches are advanced smart managed fixed-configuration Gigabit and Fast Ethernet switches designed for small businesses in an easy-to-administer solution. The series has 8 gigabit models and 5 Fast Ethernet models.

The gigabit models are : 8-, 16-, 24-, and 48-port 10/100/1000 non-PoE models; and two 8-port and two 24-port 10/100/1000 PoE models. Gigabit models have additional true Gigabit SFP ports for fiber connectivity.

The Fast Ethernet models are : 8-. 24- and 48- 10/100 non-PoE models and 8-, 24- 10/100 PoE+ models.

The Fast Ethernet models come with additional 2 combo uplink ports . All HP 1910 models support rack mounting or desktop operation.

Customizable features include basic layer 2 features like VLANs and link aggregation as well as advanced features such as Layer 3 static routing, IPv6, ACLs and Spanning Tree Protocols. HP 1910 switches come with a lifetime warranty covering the unit, fans, and power supplies.

Features

Management

- Simple Web management: allows for easy management of the switch- even by nontechnical users- through an intuitive Web GUI; http and secure http (https) is supported
- Single IP management: enables management of up to four HP 1910 devices using a single Web interface; simplifies management of multiple devices
- Secure Web GUI: provides a secure, easy-to-use graphical interface for configuring the module via HTTPS
- SNMPv1, v2c, and v3: facilitates management of the switch, as the device can be discovered and monitored from an SNMP management station
- Complete session logging: provides detailed information for problem identification and resolution

Quality of Service (QoS)

- Broadcast control: allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic
- Rate limiting: sets per-port ingress enforced maximums and per-port, per-queue minimums
- Traffic prioritization: provides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p classification; packets are mapped to four hardware queues for more effective throughput

Connectivity

- IPv6: IPv6 host: enables switches to be managed and deployed at the IPv6 network's edge. IPv6 routing: supports IPv6 static routes. MLD snooping: forwards IPv6 multicast traffic to the appropriate interface, preventing traffic flooding. IPv6 ACL/QoS: supports ACL and QoS for IPv6 network traffic.
- Auto-MDI/MDIX: adjusts automatically for straight-through or crossover cables on all 10/100/1000 ports
- IEEE 802.3X flow control: provides a flow throttling mechanism propagated through the network to prevent packet loss at a congested node
- IEEE 802.3af Power over Ethernet (PoE) ready: provides up to 15.4 W per port to power standards-compliant IP phones, wireless LAN access points, Web cameras, and more (all PoE models)
- IEEE 802.3at Power over Ethernet (PoE+): provides up to 30 W per port which allows support of the latest PoE+-capable devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3af-compliant end device; eliminates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments. (Note: applies to all PoE models, except the two 24G-PoE models which support a pre-standard implementation of PoE+)

Security

- Advanced access control lists (ACLs): enables network traffic filtering and enhances network control using MAC- and IP-based ACLs; time-based ACLs allow for greater flexibility with managing network access
- Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch
- IEEE 802.1X and RADIUS network logins: controls port-based access for authentication and accountability
- Automatic VLAN assignment: assigns users automatically to the appropriate VLAN based on their identity, location and time of day
- STP BPDU port protection: blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

Data transmission



Jumbo frames support



Yes


Latency (10-100 Mbps)



5 �s


MAC address table



8192 entries


Packet buffer memory



0.5 MB


Switching capacity



8.8 Gbit/s


Throughput



6.6 Mpps


Design



Certification



RoHS, WEEE


Form factor



1U


LED indicators



Y, Yes


Product colour



Black, Grey


Rack mounting



Yes


Safety



IEC 60950-1; EN 60950-1; UL 60950-1 2, CSA C22.2 No. 60950-1-07 2


Management features



MIB support



Y


Quality of Service (QoS) support



Yes


Switch layer



L3


Switch type



Managed


System event log



Yes


Web-based management



Yes


Multicast features



Multicast support



Yes


Network



10G support



No


Auto MDI/MDI-X



Yes


Broadcast storm control



Yes


Flow control support



Yes


Full duplex



Yes


Link aggregation



Yes


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u


Number of VLANs



256


Port mirroring



Yes


Rate limiting



Yes


Routing entries



32


Spanning tree protocol



Yes


VLAN support



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-40 - 70 �C


Package dimensions



Gross Weight (Package, kg)



3.5 kg


Packaging data



User guide



Yes


Performance



Flash memory



32 MB


Internal memory



128 MB


Processor frequency



500 MHz


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Fast Ethernet (10/100)


Combo SFP ports quantity



2


Console port



RJ-45


Power connector



DC-in jack


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Input current



10 A


Power consumption (typical)



220 Watt


Power supply included



Yes


Redundant power supply (RPS) support



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



Yes


Power over Ethernet plus (PoE+) ports quantity



24


Total Power over Ethernet (PoE) budget



180 Watt


Product dimensions



Net Weight (Product, kg)



3.5 kg


Product Depth



23.8 cm


Product Height



4.4 cm


Product Width



44 cm


Protocols



Management protocols



SNMP v1, v2c, v3, RMON


Security



Access Control List (ACL)



Yes


DHCP features



DHCP client


IGMP snooping



Yes


Security algorithms



802.1x RADIUS


SSH/SSL support



Yes


Vendor information



Brand Name


Hewlett Packard Enterprise


Warranty



1 Year(s)
