IBM 41Y8371-RFB S3700 400GB SATA 1.8" MLC 41Y8371-RFB

The IBM� SATA 1.8-inch and 2.5-inch MLC Enterprise solid-state drives (SSDs) for IBM System x� employ enterprise MLC NAND technology to bring an affordable, but performance-driven solution for applications requiring enterprise workloads with a mix of read-write operations. These industry standard 1.8-inch and 2.5-inch form factor SSD drives use a single-chip controller with a SATA interface on the system side and n-channels of NAND flash internally. They are targeted at databases and other enterprise workloads that require high I/O performance in random read and write operations including applications caching and tiering. The 1.8-inch SSDs can also be configured into the IBM eXFlash solution for maximum capacity and performance.

Features



Access time



0.1 Millisecond


Certification



UL, CSA, TUV, FCC, EMC, CE Mark, C-Tick Mark


Data transfer rate



6 Gbit/s


ECC



Yes


Interface



Serial ATA III


Linux operating systems supported



Y, Yes


Lithography



24 nm


Mean time between failures (MTBF)



2500000 Hour


Memory type



MLC


Native Command Queuing (NCQ)



Yes


Random read (4KB)



60000 IOPS


Random write (4KB)



40000 IOPS


Read speed



520 MB/s


S.M.A.R.T. support



Yes


Security algorithms



256-bit AES


SSD capacity



400 GB


SSD form factor



1.8"


Windows operating systems supported



Y, Yes


Write speed



500 MB/s


Operational conditions



Maximum operating altitude



3050 m


Non-operating vibration



1.04 G


Operating relative humidity (H-H)



8 - 85 %


Operating shock



1.5 kg


Operating temperature (T-T)



0 - 70 �C


Operating vibration



0.67 G


Other features



Internal



Yes


Package dimensions



Gross Weight (Package, kg)



1.2 kg


Power



Power consumption (read)



2.8 Watt


Power consumption (write)



4.6 Watt


Product dimensions



Net Weight (Product, kg)



1.1 kg


Product Depth



7.9 cm


Product Height



0.5 cm


Product Width



5.4 cm


Vendor information



Brand Name


IBM


Warranty



1 Year(s)
