Intel BX8071513900KF Core i9-13900KF processor 36 BX8071513900KF

Intel� Gaussian & Neural Accelerator
Intel� Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel� GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel� Deep Learning Boost (Intel� DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel� Speed Shift Technology
Intel� Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel� Turbo Boost Technology
Intel� Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don�t.

Intel� Hyper-Threading Technology
Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel� 64
Intel� 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.� Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel�s instruction set this processor is compatible with.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Enhanced Intel SpeedStep� Technology
Enhanced Intel SpeedStep� Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep� Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep� Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel� Volume Management Device (VMD)
Intel� Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Intel� Standard Manageability (ISM)
Intel� Standard Manageability is the manageability solution for Intel vPro� Essentials platforms and is a subset of Intel� AMT with out-of-band management over Ethernet and Wi-Fi, but no KVM or new life cycle management features.

Intel� Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

Intel� AES New Instructions
Intel� AES New Instructions (Intel� AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Secure Key
Intel� Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel� Boot Guard
Intel� Device Protection Technology with Boot Guard helps protect the system�s pre-OS environment from viruses and malicious software attacks.

Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel� Virtualization Technology (VT-x)
Intel� Virtualization Technology (VT-x) allows one hardware platform to function as multiple �virtual� platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel� Virtualization Technology for Directed I/O (VT-d)
Intel� Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium� processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel� VT-x with Extended Page Tables (EPT)
Intel� VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel� Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel� Thermal Velocity Boost
Intel� Thermal Velocity Boost (Intel� TVB) is a feature that opportunistically and automatically increases clock frequency above single-core and multi-core Intel� Turbo Boost Technology frequencies based on how much the processor is operating below its maximum temperature and whether turbo power budget is available. The frequency gain and duration is dependent on the workload, capabilities of the processor and the processor cooling solution.

Intel� Stable IT Platform Program (SIPP)
The Intel� Stable IT Platform Program (Intel� SIPP) aims for zero changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity for IT to effectively manage their computing endpoints.

Features



Commodity Classification Automated Tracking System (CCATS)



740.17B1


CPU configuration (max)



1


Direct Media Interface (DMI) Revision



4.0


Embedded options available



No


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



20


PCI Express configurations



1x16+1x4, 2x8+1x4


PCI Express slots version



5.0, 4.0


Scalability



1S


Supported instruction sets



SSE4.1, SSE4.2, AVX 2.0


Thermal Monitoring Technologies



Yes


Use conditions



PC/Client/Tablet


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


On-board graphics card



No


On-board graphics card model



Not available


Logistics data



Harmonized System (HS) code



8542310001


Memory



Maximum internal memory supported by processor



192 GB


Memory bandwidth (max)



89.6 GB/s


Memory channels



Dual-channel


Memory types supported by processor



DDR4-SDRAM, DDR5-SDRAM


Non-ECC



Yes


Operational conditions



Tjunction



100 �C


Other features



L2 cache



32768 KB


Maximum internal memory



192 GB


Package dimensions



Gross Weight (Package, kg)



0.21000000000000002 kg


Processor



Box



Yes


Bus type



DMI4


Cooler included



No


Efficient cores



16


Efficient-core base frequency



2.2 GHz


Efficient-core boost frequency



4.3 GHz


Maximum number of DMI lanes



8


Maximum turbo power



253 Watt


Memory bandwidth supported by processor (max)



89.6 GB/s


Performance cores



8


Performance-core base frequency



3 GHz


Performance-core boost frequency



5.4 GHz


Processor ARK ID



230497


Processor base power



125 Watt


Processor boost frequency



5.8 GHz


Processor cache



36 MB


Processor cache type



Smart Cache


Processor codename



Raptor Lake


Processor cores



24


Processor family



Intel� Core� i9


Processor generation



13th gen Intel� Core� i9


Processor manufacturer



Intel


Processor model



i9-13900KF


Processor operating modes



64-bit


Processor socket



LGA 1700


Processor threads



32


Stepping



B0


Processor special features



Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Turbo Boost Max Technology 3.0



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� Adaptive Boost Technology



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Control-flow Enforcement Technology (CET)



Yes


Intel� Deep Learning Boost (Intel� DL Boost)



Yes


Intel� Gaussian & Neural Accelerator (Intel� GNA) 3.0



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� OS Guard



Yes


Intel� Secure Key



Yes


Intel� Speed Shift Technology



Yes


Intel� Standard Manageability (ISM)



Yes


Intel� Thermal Velocity Boost



Yes


Intel� Thermal Velocity Boost Frequency



5.8 GHz


Intel� Thread Director



Yes


Intel� Turbo Boost Max Technology 3.0 frequency



5.7 GHz


Intel� Turbo Boost Technology



2.0


Intel� Volume Management Device (VMD)



Yes


Product dimensions



Net Weight (Product, kg)



0.2 kg


Technical details



Launch date



Q4'22


Status



Launched


Target market



Gaming, Content Creation


Vendor information



Brand Name


Intel


Warranty



1 Year(s)
